The carbon fiber tubes produced by Jingsheng are carbon fiber tubes made using the winding process, using epoxy resin pre-impregnated materials made from imported carbon fiber materials from Japan. The carbon fiber tubes exhibit high rigidity, excellent strength, lightweight properties, and outstanding resistance to acid and alkali. Our processes are ISO9001 certified and have undergone inspection and approval from Fortune 500 clients, such as Siemens, providing a 10-year quality guarantee for carbon fiber tube products.
Product Details
Key Features:
1. Uniform wall thickness, high inner and outer diameter precision, with tolerances controllable within 0.03mm.
2. Accurate length, with tolerances controllable within 0.05mm.
3. Straightness and roundness controllable within 0.03mm.
4. Customizable dimensions, including tube diameter, wall thickness, and length.
5. Short delivery times, with typical orders shipped within 2 weeks, and special orders can be dispatched within 3 days.
6. Providing machining services, including but not limited to drilling round holes, square holes, slant holes, chamfering, engraving, etc.
7. Reach & RoHS certification.
8. Conventional characteristics of carbon fiber tubes: lightweight, good rigidity, high strength, wear resistance, corrosion resistance, UV resistance, etc.
Specifications:
Tube Diameter |
We can provide carbon fiber tubes in various diameters, and for the majority of sizes, we have molds available. Custom sizes without molds incur separate tooling costs. Diameter range: From 6mm to 400mm, covering a wide spectrum. We also offer precise external diameter processing services, with an outer diameter tolerance controlled within ±0.01mm. |
Wall Thickness |
The wall thickness of rolled carbon fiber tubes is customizable. The rolling process involves layering carbon fiber pre-impregnated material onto molds, with the typical thickness of each layer around 0.15mm. The standard tube thickness is 1.2mm, equivalent to 8 layers, but other thicknesses are customizable. Due to the high functional requirements of carbon fiber tubes in the industries our customers are involved in, the thickness range of our currently produced carbon fiber tubes is 0.8mm to 6mm, with other thicknesses available for customization. |
Length |
The length of each unjoined carbon fiber tube is limited by molds and curing furnaces, with the longest rolled tube currently reaching 3m per section. For longer dimensions, we can provide solutions to connect multiple sections of carbon fiber tubes. If precise length requirements per section exist, we can achieve an error of ±0.1mm or better through precision machining. |
Shape |
Circular carbon fiber tubes are the mainstream shape produced through rolling, and conical tubes are also within the scope. Other shapes, such as elliptical, square, etc., require customization. |
Surface |
Rolled carbon fiber tubes have various surface styles available:
Standard gloss surface Standard matte surface Polished surface Painted surface (transparent, blue, red, yellow, etc., all customizable colors)
We also offer various patterns for the above surfaces:
UD black surface 3K plain weave 3K twill weave 12K plain weave Silver Red/black Blue/black Gold/black |
Applications:
Telescopic Poles,
Extension Tool,
Robotics,
Drone components,
Industrial equipment,
Sporting products.
