UHMWPE Sheet plate board 100% UHMW PE raw material white and black UHMW PE sheet
Negotiable
/ Piece
2 Pieces(Min. Order)
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
You May Like
-
self-lubricating flame retardant UHMW-PE 60mm UHMWPE sheet red recycled UHMW PE PE1000 plastic siding hard HUMW sheet
-
Competitive Price Self Lubricating Uhmwpe Sheet 500 Uhmwpe Board 100 Hdpe Pe Sheet Cut To Size Uhmw Plates
-
2mm-6mm PP Corrugated Sheet Edge Sealing Welding Machine special designed for Hollow Sheet Bottle Layer Pad Production 2mm-6mm
-
PP Corrugated Sheet Edge Sealing Welding Machine is special designed for Hollow Sheet Bottle Layer Pad Production
-
automatic plastic PP board pallet plate edge corner sealing welding machine for pp pe sheet, coroplast sheet layer pads
-
automatic plastic PP board pallet plate edge corner sealing welding machine for pp pe sheet, coroplast sheet layer pads
Product Description
UHMWPE Sheet Ultra High Molecular Weight Polyethylene Sheet with High Impact Resistance
UHMW PE is a kind of engineering plastic with medium price and superior properties. It has almost combines all excellent properties of plastics. It has excellent abrasion resistance, high impact resistance, self-lubricating properties ,outstanding ability against cold ,eco-friendly ,and light weight.
Characteristics
-Excellent wear resistance
-Can work under the temperature -200°C to +80°C
-Impact and noise reduction
-Chemical resistant
-No water absorption
-Anti-adhesive
-Food safe
-Light weight
Technical Data Sheet
| PROPERTIES | Test Method | Unit | Value |
| I.Physical Properties | |||
| Density | ISO 1183 | g/cm3 | 0.96 |
| Water absorption 24hrs | ISO 62 | % | 0.01 |
| II.Thermal Properties | |||
| Heat deflection temperature - HDT/A | ISO 75-2 | ºC | 42 |
| Min. service temperature | ºC | -269 | |
| Max. service temperature-Long Term | ºC | 90 | |
| Thermal conductivity at 23 ºC | DIN 11359 | W/(K*m) | 0.42 |
| Coefficient of linear thermal expansion | ISO 11359 | 10-4*K-1 | 2 |
| Flammability Rating(6mm thickness) | UL 94 | - | HB |
| III.Mechanical Properties at 23ºC | |||
| Tensile strength at yield | ISO 527-2 | MPa | 17 |
| Tensile strength at break | ISO 527-2 | Mpa | 40 |
| Elongation at break | ISO 527-2 | % | >50 |
| Modulus of elasticity after tensile test | ISO 527-2 | MPa | 650 |
| Modulus of elasticity after flexural test | ISO 178 | MPa | 800 |
| Hardness - Shore D | DIN 53505 | 61 | |
| Charpy impact strength | ISO 179 | kJ/m2 | N. B. |
| Friction coefficient | DIN 53375 | 0.25 | |
| IV.Electrical Properties at 23ºC | |||
| Dielectric constant at 1 MHz | IEC 60250 | 106Hz | 3.1 |
| Dielectric loss factor at 1 MHz | IEC 60250 | 106Hz | 0.0001 |
| Volume resistively | IEC 60093 | Ohm (Ω) * cm | >1014 |
| Surface resisively | IEC 60093 | Ohm (Ω) | >1011 |
| Dielectric strength | IEC 60243-1 | kV/mm | 45 |
| NOTE: 1 g/cm3 = 1,000 kg/m3, 1 Mpa = 1 N/mm2, 1kV/mm = 1 MV/m | |||
