VB180086 RHB51P Turbo Charger VA180086 VA190019 VA59B VB180086 Turbocharger 35242061F 17770549F

VB180086 RHB51P Turbo Charger VA180086 VA190019 VA59B VB180086 Turbocharger 35242061F 17770549F photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2007
Overseas Office:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

VB180086 RHB51P Turbo charger VA180086 VA190019 VA59B VB180086 turbocharger 35242061F 17770549F



Welcome to contact us :

Whatsapp / Wechat :+86 18262294090 Skype : _15

QQ: 1127776325

Products description





Part NumberVB180086
Previous VersionVA180086, VA190019
OE number35242061F, 17770549F, 860025, 91153668, 4796000, 4864756
Year1995-02
V-SPEC.VA59B
Description
CHRAVA810045
Turbo ModelRHB51P, RHB51P-56005IPP10.5NHBRL3730CEZ
Displacement2.5L, 2499 ccm
KW85/115 HP
FuelDiesel
Engine25TDS (VM41B)
Angle α (compressor housing)0
Angle β (turbine housing)330
Bearing HousingNN133397
Turbine WheelNN131624
Comp. WheelNN136614
Back plateNN133021(64T-002)
Heat ShieldNN137055(38T-013)
Repair KitNN139656
Turbine HousingNN139624
Compressor CoverNN133921
Turbine Housing AR10.5
ActuatorNH960751
Settings Waste gate (pressure)1.602 bar
Settings Waste gate (lift shaft)2.00 mm
Gasket (turbine inlet)210229
Gasket (turbine outlet)210232
Gasket (oil outlet)210636











Products show



VB180086 RHB51P Turbo charger VA180086 VA190019 VA59B VB180086 turbocharger 35242061F 17770549F





Turbo parts

The turbocharger parts  including Turbo  Chra ( turbo  core / cartridge  ) , Turbo actuator valve, Nozzle Ring ,Repair  kit ,Compressor  wheel,Turbine wheel,Turbine  shaft , Journal bearing ,Thrust collar,Bearing housing ,Turbine housing,Compressor housing,Bypass-valve and so on

 VB180086 RHB51P Turbo charger VA180086 VA190019 VA59B VB180086 turbocharger 35242061F 17770549F

Packages



plastic papershock bubble, neutral carton,pallet or as your requirements



VB180086 RHB51P Turbo charger VA180086 VA190019 VA59B VB180086 turbocharger 35242061F 17770549F





Shipment



Usually we send our goods via EMS,UPS,DHL,FEDEX ,TNT and so on.batch order send by sea, Would you want to ship them by the other way ,please feel free to contact me!

VB180086 RHB51P Turbo charger VA180086 VA190019 VA59B VB180086 turbocharger 35242061F 17770549F







Why you choose us?



1.We are  Assessed Gold Supplier and trade assurance .



2.We have our own factory , best production capability ,best quality control, Best Service .



3. Inspected by the Inspection Institution of SGS /CE /ISO.



4. 100% qualified inspection Before Shipment .



Company Profile



1.Wuxi Booshiwheel Power Technology Co,Ltd.,established in 2002,is engaged in designing and producing turbochargers and turbo parts that are used in vehicle and engineering machinery.We can also provide maintenance and technological services.



2.The company has imported Japanese advanced equipments,such as assembly line,processing production line and high speed balance,as well as the latest testing facilities.



3.The company’s business concept are “make contribution to the development of society by technology” and “talent is the biggest and unique wealth”,focus on manufacturing global the most cost-effective turbochargers.





Last ,we are looking forward to cooperating with you .
