Shacman Truck Accessories 8-speed 9-speed 10-speed 12-speed 16-speed Gearbox Hydraulic Retarder
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2014
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Brand New PTO QH70 Made in China From OriginalNegotiableMOQ: 1 -
Factory Price FAST Gearbox 8JS105A 8JS85C for Dongfeng Truck PartsNegotiableMOQ: 1
-
Heavy Truck Gearbox Accessories Mine Truck Dump Truck Gearbox FHB400 Hydraulic Retarder Shacman HOWO FAST Gearbox AccessoriesNegotiableMOQ: 1
-
Heavy Duty Truck Driveline FHB400FAST Transmission Retarder PartsNegotiableMOQ: 1
-
For Truck Transmission Parts Countershaft Gear Transmission Gearbox WG2210020402NegotiableMOQ: 1
You may also like |
||||||||
Product Description
item |
value |
OE NO. |
FHB400 |
Type |
Transmission Assembly |
Size |
Size standards |
Place of Origin |
SHN |
Brand Name |
fast |
Model Number |
FHB400 |
Truck Model |
Shacman SINOTRUK (CNHTC) MAN - Europe Foton Heavy Duty |
Year: |
2008-,2007-,1982-1986-,2005-,2007-2013-,2005-,2006-,2009-,2012-, |
OE NO: |
FHB400 |
Product name: |
Truck Transmission Retarder FHB400 |
Materials: |
Steel / Aluminium |
Quality: |
Original and genuine |
Conditions: |
100% original and brand new |
Size : |
Size standards |
Reference number: |
FHB400 |
Certification: |
ISO |
Delivery: |
7-15 days |
Performance
There is a stator with blades and a rotor with blades in the working chamber of the hydraulic retarder, and the rotor rotates together with the drive shaft. When the retarder is working, the ECU controls the opening of the proportional valve to pump the gas from the whole vehicle gas source into the retarder oil cell shell, and the gas presses the retarder oil into the working chamber.
The rotor rotates at high speed and hits the oil on the stator, generating a reaction force, i.e. braking torque, which in turn acts to reduce the speed of the vehicle (the more oil, the greater the reaction force). The heated oil flows out of the working chamber and into the heat exchanger, where the heat is taken away by the engine coolant and transferred to the atmosphere through the engine cooling water tank.
The retarder converts the kinetic energy of the vehicle into heat energy, which is then transferred to the atmosphere through the engine water circulation system to achieve constant speed and deceleration of the vehicle. As the retarder is a braking force generated by churning oil, the retarder force is very weak when the drive shaft speed is too low. Generally the vehicle can exert a lot of braking power at speeds above 30km/h.
Performance
Retarder is only an auxiliary braking device, emergency braking and stopping still need to apply the brakes.
The size of the retarder power has nothing to do with the engine speed, only with the drive shaft speed (car speed), but the engine speed will affect the speed of the water cycle, the engine speed is too low, the retarder water temperature can easily rise, beyond the limit, the retarder will drop the torque or quit, affecting the retarder use time and effect. So constant speed gear, the engine speed should generally be maintained at 1500 rpm or more.
The power of the retarder is not affected when the gearbox is in neutral, only the engine speed is in idle when in neutral, only about 800 rpm, the water circulation is too slow, the retarder will quit after a few dozen seconds of use, so the retarder cannot be put in neutral when the gearbox is in use.
In an emergency (non-slippery or turning conditions), you can directly pull the retarder in the highest gear to achieve the role of fast braking, will not damage the retarder. However, due to the rapid rise in water temperature, the retarder will exit at high temperature within ten seconds or so and lose braking power.
FAST Transmission Fluid Retarder in all models
ZF Vanillian Complete range of gearboxes
We have been in the gearbox industry for 20 years. We support customization and sample delivery and want to be your quality supplier.
Packing & Delivery
Packing details:inner plastic packaging,extemal carton packaging
DeliveryTime:20 days after payment
Any port in China
Company Profile
Shaanxi Xinshi Hongtai Trading Co., Ltd. is located in the beautiful ancient city of Xi'an. It is a professional trading company with qualified products and the right to import and export business approved by the national authorities. We provide one-stop service for our customers, mainly selling heavy duty auto parts, Shakman trucks, Dongfeng Volvo trucks, China Heavy Duty Truck, FAW Jiefang, sprinklers, suction trucks, fire trucks, buses and other auto parts such as gearboxes, clutches, brakes and braking systems, steering systems, engine parts, bearings, lubricants and so on.
We do business with customers from all over the world and we consider all cutters to be our target. We want to build long-term business relationships.
With our customers
Customer satisfaction is our number one priority and we adhere to a quality first philosophy. Customer first" we will continue to provide our customers with high quality products and the best service to build long term relationships
FAQ
1. who are we?
We are based in Shaanxi, China, start from 2021,sell to Domestic Market(80.00%),Africa(10.00%),Southeast Asia(10.00%),South Asia(0.00%),Eastern Asia(0.00%),North America(0.00%),South America(0.00%),Oceania(0.00%),Western Europe(0.00%),Southern Europe(0.00%),Central America(0.00%),Northern Europe(0.00%),Eastern Europe(0.00%),Mid East(0.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Engine Parts, Cluth Disc & Cluth Pressure Plate, Truck Bearing, Gear Box & Accessories, Chassis Part
4. why should you buy from us not from other suppliers?
Shaanxi Xinshi Hongtai Trading Co., Ltd. is located in the beautiful ancient city of Xi'an. It is a professional trading company with qualified products and the right to import and export business approved by the national authorities. We provide one-stop s
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
We are based in Shaanxi, China, start from 2021,sell to Domestic Market(80.00%),Africa(10.00%),Southeast Asia(10.00%),South Asia(0.00%),Eastern Asia(0.00%),North America(0.00%),South America(0.00%),Oceania(0.00%),Western Europe(0.00%),Southern Europe(0.00%),Central America(0.00%),Northern Europe(0.00%),Eastern Europe(0.00%),Mid East(0.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Engine Parts, Cluth Disc & Cluth Pressure Plate, Truck Bearing, Gear Box & Accessories, Chassis Part
4. why should you buy from us not from other suppliers?
Shaanxi Xinshi Hongtai Trading Co., Ltd. is located in the beautiful ancient city of Xi'an. It is a professional trading company with qualified products and the right to import and export business approved by the national authorities. We provide one-stop s
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
