New Condition 75 KW Building Machinery Cost-effective Small Backhoe Loader With Rear Bulldozer Blade for Highway Construction
US$ 3000 - 49800
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
SEM
Place of Origin:
China
Model Number:
FOCUS 149
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
20 days
Related Products
-
China Made Used Bulldozer SD16 Remote Control Bulldozer Crawler Bulldozer,Good Condition CAT D6R Used Dozer Bulldozer Caterpillar Crawler Bulldozers for Sale D4 D5 D7 D10 D11 Original ProvidedUS$ 9000 - 49800MOQ: 1 Unit -
China Made Used Bulldozer SD16 Remote Control Bulldozer Crawler Bulldozer,Good Condition CAT D6R Used Dozer Bulldozer Caterpillar Crawler Bulldozers for Sale D4 D5 D7 D10 D11 Original ProvidedUS$ 9000 - 49800MOQ: 1 Unit
-
Asphalt Paving Machines: Screeds & Asphalt Pavers,RP905IV 177KW 8.85M Construction Asphalt Concrete Paver For SaleUS$ 2000 - 56900MOQ: 1 Unit
-
China Top Brand RP603L 6m Wheel Asphalt Paver for Sale,Road Making Machine Paving Width 4.5m Mini Asphalt Road Paver for SaleUS$ 9000 - 72000MOQ: 1 Unit
-
Chinese Factory Construction Machines, Asphalt Machine Road Paver, Best Selling High Quality Concrete Asphalt Road Paver Making Machine For Civil Engineering Road Construction Made In ChinaUS$ 7000 - 49800MOQ: 1 Unit
Brand Name
SEM
Place of Origin
China
Model Number
FOCUS 149
After-sales Service Provided
Overseas third-party support available
Condition
New
Dimension(Long * Breadth * High)
6600*3180*3080mm
Machine Weight
17250 - 17500 Kg
Moving Type
Crawler Bulldozer
Sem Factory Sem822 D Bulldozer 220HP Crawler Bulldozer with Bottom Price Easy to Operate Crawler Bulldozer
The electronically controlled hydrostatic drive system and multi functional joystick provide high levels of performance and maneuverability.The cabin is ergonomically designed for increased operator comfort and visibility. The advanced monitoring system tracks machine operating conditions and keeps the operator informed of all vital machines functions.The proven hydrostat design along with world class pump and motors provide a highly reliable tractor. The undercarriage components are designed for longer life versus the leading competitor.The SEM tractors are designed for easy access to reduce overall maintenance time.The machines electronic control module allows for quick troubleshooting.
| Model | |||||
| Model | SEM816D | SEM816D LGP | SEM816D DS | SEM816D CH | SEM816D FR |
| Main Configuration | |||||
| Operating Weight | 17,560kg | 20,150kg | 20,420kg | 17,820kg | 18,580kg |
| Ground Pressure | 66.8kPa | 31.1kPa | 34.8kPa | 61.8kPa | 66.9kPa |
| Ground Clearance | 410mm | 410mm | 410mm | 410mm | 410mm |
| Max. Slope | 30 | 30 | / | 30 | 30 |
| Engine | |||||
| Engine Model | WD10G178E25 | WD10G178E25 | WD10G178E25 | WD10G178E25 | WD10G178E25 |
| Rated Power | 131kW | 131kW | 131kW | 131kW | 131kW |
| Working Tool | |||||
| Blade Type | SU / S | LGP | LGP | U | SU Forestry / S Forestry |
| Blade Capacity | 4.3m / 3.5m | 3.4m | 3.4m | 5.6m | 6m / 5.8m |
| Blade Width | 3,180mm / 3,590mm | 4,410mm | 4,410mm | 3,580mm | 3,180mm / 3,590mm |
| Blade Height | 1,240mm / 1,165mm | 1,000mm | 1,000mm | 1,400mm | 1,625mm / 1,625mm |
| Max. Blade Digging Depth | 430mm / 430mm | 470mm | 470mm | 430mm | 430mm / 430mm |
| Max.Blade Lift Ground Clearance | 1,041mm / 1,041mm | 1,055mm | 1,055mm | 1,041mm | 1,041mm / 1,041mm |
| Max.Output Rimpull | 280kN | 280kN | 280kN | 280kN | 280kN |
| Max. Digging Depth of Ripper | 584mm | / | / | 584mm | 584mm |
| Max. Clearance Under Tip | 615mm | / | / | 615mm | 615mm |
| Powertrain | |||||
| Type | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system |
| Travel Speed-F/R | infinitely variable speeds 0-10 km/h | nfinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h |
| Steering & Brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake | hydrostatic steering; wet, multi-disc brake |
| Minimum Streeing Radius | 3,610mm | 3,740mm | 3,740mm | 3,610mm | 3,610mm |
| Undercarriage | |||||
| Track Shoe Width-Single | 510mm | / | 950mm | 560mm | 560mm |
| Track Shoe Width-APEX | / | 1,050mm | 950mm | / | / |
| Track Shoe Quantity | 37 | 42 | 42 | 37 | 37 |
| Track Length On Ground | 2,430mm | 2,925mm | 2,925mm | 2,430mm | 2,430mm |
| Track Gauge | 1,880mm | 2,300mm | 2,300mm | 1,880mm | 1,880mm |
| Track Roller Quantity | 6 | 7 | 7 | 6 | 6 |
| Carrier Roller Quantity | 2 | 2 | 2 | 2 | 2 |
| Hydraulic System | |||||
| Type | center close, pilot control | center close, pilot control | center close, pilot control | center close, pilot control | center close, pilot control |
| Implement Hydraulic System Pressure | 19MPa | 19MPa | 19MPa | 19MPa | 19MPa |
| Service Refil Capacities | |||||
| Fuel Tank | 320L | 320L | 320L | 320L | 320L |
| Cooling System | 45L | 45L | 45L | 45L | 45L |
| Hydraulic Tank | 140L | 140L | 140L | 140L | 140L |
| Pivot Shaft Case(each side) | 1.2L | 1.2L | 1.2L | 1.2L | 1.2L |
| Engine Crankcase | 24L | 24L | 24L | 24L | 24L |
| Final Drive(each side) | 30L | 40L | 40L | 30L | 30L |
