Help CenterYOKOGAWA AIP830-001 – High-reliability Analog Input Module for Process DCS/PLC I/O
Related Products
-
CP451-51 Processor Module Safety Instrumentation System (SISNegotiableMOQ: 1 Bag -
CP451-50 Processor ModuleNegotiableMOQ: 1 Bag
-
YOKOGAWA ALR121-S00 – Alarm/Relay Output Interface for Plant Annunciation and Discrete SignalingUS$ 2945.00MOQ: 1 Pallet
-
YOKOGAWA A1P830 – Rack Power Supply Module for Process Control CabinetsNegotiableMOQ: 1 Combo
-
YOKOGAWA AAI143-S00 – 8‑Channel 4–20 mA Analog Input Module With HART for FIO-based DCSNegotiableMOQ: 1 Combo
Warranty period: 365 days
Delivery time: 1 week for in-stock; no more than one month at the latest
Payment: 50% advance payment; full payment for delivery
Express delivery: FedEx, UPS, DHL
We provide pre-shipment functional checks and packing suitable for export and on-site spares rooms.
Multi-channel analog input – Typically provided as an 8-channel AI card for 4–20 mA and voltage inputs used in process monitoring.
Backplane-powered integration – Draws power from the Yokogawa baseplate/backplane; no separate field PSU required for the module itself.
Noise-robust design – Suited for industrial cabinets with grounding and shielding practices common to Yokogawa DCS/PLC nodes.
Channel isolation and diagnostics – In many cases, channel-to-bus isolation and basic line diagnostics help reduce nuisance trips and simplify troubleshooting.
HART pass-through (where applicable) – You might notice HART device data can be passed upstream on 4–20 mA channels, supporting smart transmitters and asset tools.
Cabinet-friendly form factor – Slim card width helps when space is tight during unit expansions or partial migrations.
Variant “-001” hardware – The -001 suffix typically denotes a specific hardware revision aligned with common Yokogawa I/O bases.
| Brand / Model | YOKOGAWA AIP830-001 |
| HS Code | 8538.90 (Parts for switching/protection/control apparatus) |
| Power Requirements | Backplane powered (typ. 5 V/24 V supplied by the Yokogawa I/O node); no external module PSU |
| Dimensions & Weight | Approx. 130 (H) × 27 (W) × 130 (D) mm; ~0.25 kg, typical Yokogawa I/O card form factor |
| Operating Temperature | 0 to +55 °C (industrial control cabinet environment) |
| Signal I/O Types | Analog Input: 4–20 mA, 1–5 V, mV ranges; RTD/TC variants exist depending on system configuration |
| Channel Density | 8 AI channels typical for the -001 hardware variant |
| Communication Interfaces | Internal system bus via Yokogawa backplane; HART pass-through commonly supported on 4–20 mA inputs |
| Installation Method | Plugs into Yokogawa I/O baseplate; baseplate mounts on DIN rail or panel within standard control cabinets |
Application FieldsThe AIP830-001 is typically used in process industries where stable and accurate analog measurement is essential:
Oil & Gas – wellhead pressure, separator levels, and pipeline flow transmitters
Chemicals & Petrochemicals – reactor temperature loops, utility skids, dosing systems
Power Generation – boiler drum level, condenser vacuum, turbine auxiliary monitoring
Water & Wastewater – influent/effluent flow, pH transmitters, chlorine residual
Food & Beverage / Pharma utilities – CIP/SIP skid monitoring, chilled water loops
“We swapped in AIP830-001 cards during a short outage—channel mapping stayed consistent and commissioning finished a day early.” — Maintenance Supervisor, midstream plant
Advantages & ValueReliability for 24/7 operation – The module’s noise immunity and isolation, in many cases, reduce spurious trips and downtime.
Seamless compatibility – Designed for Yokogawa backplanes, which usually means faster installs and fewer wiring changes.
Lifecycle cost savings – Standardized spares across cabinets simplify stocking and help cut carrying costs.
HART-enabled maintenance – When enabled, pass-through diagnostics can shorten loop checks and improve device health insight.
Supported by experienced teams – We can pre-test modules and advise on baseplate and terminal selection to keep projects moving.
Cabinet environment – Install in a ventilated control cabinet; maintain 0–55 °C ambient and humidity control to limit condensation.
Wiring practices – Use shielded twisted pairs for 4–20 mA/mV inputs. Land shields on a single-point ground to minimize noise loops.
Baseplate/backplane – Fit the card to the matching Yokogawa baseplate; verify keying and slot position before power-up.
Loop checks – After installation, perform a loop test with a calibrated source; verify range, damping, and HART device tags if used.
Routine maintenance – Periodically check terminal tightness, clean dust with dry air, and review firmware/engineering configuration backups.
Safety – De-energize the backplane before card insertion/removal unless the system specifically supports hot-swap for this model.
Yokogawa I/O baseplate/backplane – Required for power and system-bus connection.
Terminal blocks – Matching field wiring terminals for mA/Volt signals and optional HART filtering.
Node/controller unit – Integrates the module to the DCS/PLC network based on your Yokogawa architecture.
CE compliant (typical for Yokogawa industrial I/O)
RoHS compliant hardware in many cases
UL recognition commonly available for control cabinet use
Manufacturer’s warranty support plus our 365-day warranty coverage
