Low Cost 2D Electronic Compass

It is a high-precision two-dimensional electronic compass, which measures the azimuth from 0 to 360°. It is composed of industrial microcontroller with high reliability and strong anti-interference ability, high-precision magnetic sensors and drive chips, and integrates hard magnetic interference and soft magnetic interference compensation technology. It can be customized according to customer needs, and it is very convenient to quickly integrate the electronic compass function into various products.
The product is small in size and low in power consumption, and can be used in many fields such as antenna stability, automotive, and system integration. Strong shock resistance, can work normally in extremely harsh environments, which is more suitable for today's miniaturized high-precision measurement.

Features
Measurement range 0~360°
Heading accuracy 1°, tilt range ±5°
Industrial grade design
Input voltage DC 5V
Wide temperature working -40~+85℃
With hard magnetic, soft magnetic and tilt compensation
Baud rate 2400~115200 (adjustable)
Working current: 40mA
IP67 protection level
Output RS232/RS485/TTL/MODBUS (optional)
Small volume (55*37*24mm) (customizable)

Applications
Individual combat equipment
Satellite solar antenna positioning
AGV car
Mining machinery, oil logging equipment
Medical equipment
Gimp leveling
UAV positioning and navigation
Tilt based monitoring
Various construction machinery angle control
Inspection of bridges and dams
