1. Compact structure, small dimension, light weight and easy to disassemble and reassemble;
2. High efficiency drilling with hydraulic feeding structure;
3. High mechanization, low labor intensity;
4. Geotechnical investigation for road, building construction; blasting hole drilling;
| 1. DRILLING CAPABILITY | |||||
Drilling Dia(mm) |
75 |
110 |
|||
Drilling Depth(m) |
30 |
15 |
|||
Drilling Rod Dia(mm) |
42 |
||||
2. ROTARY TABLE | |||||
Speed(rpm) |
136 338 578 r/m |
||||
Max Torque |
350N·m |
||||
Feeding Travel |
400mm |
||||
Max Feeding Force |
8KN |
||||
Max Lifting Force |
10KN |
||||
3. Hoist | |||||
Bobbin Dia |
φ90mm |
||||
Steel Rope Dia |
φ8mm |
||||
Bobbin Rope Capacity |
18m |
||||
Max Hoisting(Single Rope) |
4KN |
||||
| Max Hoisting Speed Single Rope (2nd Layer) m/s | 0.46 1.15 1.97 | ||||
4. Oil Pump | |||||
Model |
CBW-F314-ALP Gear Oil Pump |
||||
Displacement |
14mL/r |
||||
Rated Speed |
2500r/min |
||||
Rated Pressure |
20Mpa |
||||
Max Pressure |
25Mpa |
||||
5. Engine |
Model |
Power |
Speed |
Weight |
|
(1) Electric Motor |
Y132M-4 |
7.5KW |
1440r/min |
81kg |
|
(2) Diesel Engine |
ChangchaiI R180 |
5.7KW |
2600r/min |
72kg |
|
6. Rig Dimension |
1510×600×1055mm |
||||
7. Weight(Engine not included) |
260kg |
||||
