Help CenterBasler Ace AlA640-300gm
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Color
Black
The Basler acA640-750um USB 3.0 camera with the ON Semiconductor PYTHON 300 CMOS sensor delivers 751 frames per second at VGA resolution.
General Information
| Order Number | 106748 |
|---|---|
| Product Family | ace U |
| Product Line | ace U |
| Camera Category | Area Scan Camera |
Sensor
| Sensor Vendor | onsemi |
|---|---|
| Sensor | PYTHON 300 |
| Shutter | Global Shutter |
| Sensor Format | 1/4" |
| Sensor Diagonal | 3.84 mm |
| Sensor Type | CMOS |
| Sensor Size | 3.07 mm × 2.3 mm |
| Resolution (H x V) | 640 px x 480 px |
| Resolution | VGA |
| Pixel Size (H x V) | 4.8 μm x 4.8 μm |
| Frame rate | 751 fps |
| Mono/Color | Mono |
| Spectrum | Visible |
EMVA Data
| Quantum Efficiency (typical/minimal) | 52 % (typical) |
|---|---|
| Dark Noise (typical/maximal) | 10.5 e¯ (typical) |
| Saturation Capacity (typical/minimal) | 7.1 ke¯ (typical) |
| Dynamic Range (typical/minimal) | 56.6 dB (typical) |
| Signal-to-Noise Ratio (typical/minimal) | 38.5 dB (typical) |
Camera Data
| Interface | USB 3.0 |
|---|---|
| Image Data Interface | USB 3.0, nominal max. 5 Gbit/s (SuperSpeed) |
| Pixel Bit Depth | 10 bits |
| Exposure Control |
|
| Digital Input | 1 |
| Power Supply | Via USB 3.0 interface |
| Power Requirements (typical) | 3 W |
Housing
| Housing Type | Box |
|---|---|
| Housing Size (L x W x H) | 29.3 mm x 29 mm x 29 mm |
| Weight | 80 g |
| Lens Mount | C-mount |
| Operating Temperature | 0 °C - 50 °C |
Manufacturer
| Basler |
|---|
