EPS Sandwich Panel Glue Spraying Production Line/PU Sandwich Panel PU Dispensing Machine
US$ 12000 - 15000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Whatsapp+86 134 2516 4065
Place of Origin:
China
Model Number:
Whatsapp+86 134 2516 4065
Payment & Shipping
Payment Methods:
Port of Shipment:
Whatsapp 0086 134 2516 4065
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Caravan Sandwich Panels Glue Dispensing Machine Glue Spraying Machine PU Spraying Machine PU Potting MachineUS$ 12000 - 15000MOQ: 1 Piece -
Magnesite Boards (MGO Board) Glue Spraying Machine PU Spraying Machine PU Laminate MachineUS$ 12000 - 15000MOQ: 1 Piece
-
Fiberboards Glue Spraying Machine PU Spraying Machine Glue Applicator PU Dispensing MachineUS$ 12000 - 15000MOQ: 1 Piece
-
Spc Panel Glue Spraying Machine Glue Dispensing Machine Glue ApplicatorUS$ 12000 - 15000MOQ: 1 Piece
-
Precise Two Component Glue Potting Machine Power Supply Insulation Potting DeviceUS$ 12000 - 15000MOQ: 1 Piece
Brand Name
Whatsapp+86 134 2516 4065
Place of Origin
China
Model Number
Whatsapp+86 134 2516 4065
Certification
Whatsapp+86 134 2516 4065
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
Whatsapp+86 134 2516 4065
Weight
Whatsapp+86 134 2516 4065
Dimension(L*W*H)
Whatsapp+86 134 2516 4065
Condition
New
Voltage
Whatsapp+86 134 2516 4065
Power(W)
Whatsapp+86 134 2516 4065
EPS Sandwich Panel Glue Spraying Production Line/PU Sandwich Panel PU Dispensing Machine
The glue Spraying line is based on the reform of the traditional roller glue machine process. With the marketization and standard scale of stainless steel furniture, all-aluminum furniture, and whole-house customization, the demand for new building materials is increasing day by day. In order to better meet the market According to the needs of customers, the functions are constantly upgraded and updated. In the building materials composite industry, the problems faced by customers are the diversification of products, the personalization of sizes and the huge quantity. The basic functions of this equipment are:
1.Automatic edge finding: (automatic recognition) automatically adjusts the glue spraying position according to the size and length of the board;
2. Automatic glue amount: (automatically adjusts the speed of glue dispensing according to the size of the board and the conveying speed);
3. Automatic feeding: When the glue volume in the glue barrel is lower than the set lower limit, the glue adding process will be automatically started.
4. One-click start: Eliminate the tedious preparation work before starting up, and realize automatic operation to working status with one click;
5. Glue heating: The equipment is equipped with glue heating and heat preservation functions, so that the glue is not restricted by ambient temperature and region, allowing customers to choose the brand of glue more freely;
6. Anti-sedimentation mixing: A glue barrel is equipped with an intelligent control mixing device to prevent precipitation or stratification caused by long-term stasis of glue, and to ensure that the glue is heated evenly when heated.
7. Visual mixing: The equipment adopts imported dynamic mixing tubes and is matched with Taiwan's high-speed brushless motor to achieve adjustable mixing speed and direct viewing of the mixing status to ensure uniform mixing;
8.Disassembly-free automatic cleaning: The equipment adopts a high-pressure gas-liquid automatic switching cleaning device. There is no need to disassemble the glue spray head, achieving true disassembly-free cleaning in the industry, and the cleaning effect is visible to the naked eye;
9.Patented glue-controlled suction valve: The equipment is equipped with our company's patented glue-controlled anti-drip suction valve, which can open the glue in time and close the glue quickly with suction adjustment;
10.Special metering pump: The equipment adopts a special polyurethane high-flow and wear-resistant precision metering pump , which can accurately control glue and adjust the flow rate to achieve an accuracy of ±0.5%, effectively avoiding inaccurate proportions and greatly improving the product qualification rate;
The overall cold plate bending process of the equipment +special industrial profiles ensure smooth operation, beauty and elegance. The conveyor line adopts German friction transmission method, which can realize stop and start, automatically adjust the conveying tension, and realize glue dispensing without gaps and noise;
The swing arm adopts a high-speed module for reciprocating spray coating and is equipped with a precision servo motor to effectively and accurately control the glue spraying position and leave a reasonable margin to prevent glue from overflowing)
