Product Description

 YRT series turntable bearing with a set of radial roller, two groups of thrust roller cage full components of composite structure design, an outer ring, a l-shaped inner ring and the inner ring, inner and outer ring with mounting holes, and before delivery or addition of pre-load, not only simplify the structure of the components,  reduced the workload of installation, reducing the high requirements for installation.Therefore, for low-speed and short-time operation occasions with high precision, high rigidity and bearing joint load requirements, such as dividing table and rotary milling head, it is extremely suitable to choose YRT series rotary table bearing.

The YRT200 rotary table Bearing inner ring and outer ring forging material:GCr15SiMn ,GCr15, Chrome steel
The YRT200 Bearing roller material : GCr15SiMn ,GCr15, Chrome steel
The YRT200 Bearing Inner ring and outer ring hardness: 58-62HRC
The manufacture process including: Lathe process, Heat treatment process, Grinding process, Assembly process and final inspect process and on on.
The delivery time:10-20 days
The package: standard export wooden case or carton boxes.

YRT200 rotary table bearing is a kind of bearing fixed by a bidirectional thrust bearing and a centripetal-guided bearing. They can support radial loads, axial loads from both directions and tilting moments free from clearance and are particularly suitable for bearing arrangements with high requirements for running accuracy,like rotary tables, millings heads and reversible clamps chucks , milling heads, measuring instruments , test equipment as well as rotary turntable.
.Due to the fixing holes in the bearing rings, the units are very easy to fit.


 YRTM rotary table bearing

Bearing type  boundary dimensions  fixing holes
d D H H1 HM C DM D1 J J1 inner ring outer ring
unit: mm mm   mm
YRTM150 150 240 41 27 10 12 214 214 165 225 7 11 6.2 34 7 33
YRTM180 180 280 44 30 10 15 244.5 244 194 260 7 11 6.2 46 7 45
YRTM200 200 300 45 30 10 15 271.2 274 215 285 7 11 6.2 46 7 45
YRTM260 260 385 55 36.5 13.5 18 343.8 345 280 365 9.3 15 8.2 34 9.3 33
YRTM325 325 450 60 40 15 20 412.6 415 342 430 9.3 15 8.2 34 9.3 33
YRTM395 395 525 65 42.5 17.5 20 485.5 486 415 505 9.3 15 8.2 46 9.3 45
YRTM460 460 600 70 46 19 22 557.7 560 482 580 9.3 15 8.2 46 9.3 45

YRT200 Rotary table bearing in stock for test equipment,quality guaranteeYRT200 Rotary table bearing in stock for test equipment,quality guarantee

Our Services

 1.custom-made according to the requirements

2.The required bearing inner ring, outer ring, height, and other detailed data can communicate with our engineers directly.

YRT200 Rotary table bearing in stock for test equipment,quality guaranteeYRT200 Rotary table bearing in stock for test equipment,quality guarantee

Application fields

YRT200 Rotary table bearing in stock for test equipment,quality guarantee

FAQ

1.Q: Are you trading company or manufacturer ?

A: We are professional slewing bearing manufacturer with 20 years’ experience.

2.Q: How long is your delivery time?

A: A: Generally it is 4-5 days if the goods are in stock. or it is 45 days if the goods are not in stock, Also it is according to quantity.

3.Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample, it is extra

4.Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment

5.Q: Can you provide special customization according to the working conditions?

A: Sure, we can design and produce the slewing bearings for different working conditions

6.Q: How about your guarantee?

A: We provide lifelong after-sales technical service



7. Q:Which Certificate your factory have ?

A: We have BV, ABS, DNV, ISO9001 certificate.

8. Q: What is your contact information?

A: Whatsapp/Wechat/Mob:8618603790073
