Type |
• Single row four point contact ball slewing bearing • Single row crossed cylindrical roller slewing bearings • Double row ball slewing bearings •Double row Roller/ball combination slewing bearing •Three-Row Roller Slew Ring Bearing |
|
Rollng elements |
Steel ball / Cylinder Roller |
|
Rollng elements Material
|
GCr5/GCr15SiMn/Customized |
|
Bearing Material |
50Mn/42CrMo/42CrMo4V /Customized |
|
Cage Material |
Nylon/ steel /copper |
|
Structure |
taper pin , Mounting holes,Inner ring ,grease fitting,load plug, seals , roller ,spacer balls or separators |
|
Outer diameter |
50-10000mm |
|
Bore size |
50-10000mm |
|
Mounting hole |
Through hole/Tapped hole |
|
Raceway hardness |
55-62HRC |
|
Inner and outer ring modulation hardness |
229-269HB/Customized |
|
Gear type |
No gear ,Internal gear , External gear. |
|
Embellish grease |
EP2 lithium lubricating grease |
|
Certificate |
ABS.BV,DNV,ISO9001,GL |
|
Packing details |
1,Filling with anti-rust oil 2.Corved with Plastic paper 3.Corved with kraft paper 4.Corved with Blue tie 5.Put in wooden box |
|
Payment term |
T/T is our first choice |
- Crossed roller bearings are also called crossed roller bearings. The rolling elements are generally cylindrical rollers or tapered rollers arranged in a crisscross arrangement on a single raceway, and the rollers are separated by cages or spacers.
- It has high rotation accuracy, large load capacity, small size and high rotation speed and rigidity, and has a wide range of uses and superiority that other bearings cannot match.
- It is suitable for applications such as joint parts or rotating parts of industrial robots, rotating worktables of machining centers, rotating parts of manipulators, precision rotating worktables, turrets, and medical instruments.


1.Q: Are you a trading company or a manufacturer?
A: We have our own factory, with 20 years of experience in slewing bearings, our type is factory + trade.
2.Q: What is your company's MQQ?
A: There are 100 MQQs. We are happy to grow with all customers, no matter how big or small, we will become bigger and bigger with you.
3.Q: Can you accept OEM and customize it?
A: Yes, we can customize it for you according to samples.
4.Q: Can you provide samples for free?
A:Yes, we can provide samples for free. Would you mind buying her tickets?
5.Q: Can you provide door-to-door service?
A: Yes, by express (GHL, FEDEX, TNT, EMS, it takes 4-10 days to reach your city.)
6. Q: How long is your delivery time?
A: If there is stock, it is within 7 days; if there is no stock, it is 25-45 days, which also depends on the quantity.
7.Q: What are your payment terms?
A: Payment <= 1000USD, 100% in advance. Payment >= 1000USD, 30% T/T in advance, balance before shipment; usually T/T, PayPal.
8.Q: Does your factory have a certificate?
A: Yes, we have BV, ABS, DNV, GL ISO9001 certificates. If you want other CE-like products, we can serve you.
