Description:
By combining Low-E coatings, standard and high performance tinted glass, reflective coatings, silk-screened patterns, laminated glass products and more, a wide variety of insulating glass configurations are available to satisfy a wide range of performance and aesthetic requirements. IG units can be fabricated to meet state energy and safety codes, sound control and seismic requirements, impact, bullet, hurricane and blast resistance requirements. IG units can be designed to reduce heat loss and solar heat gain entering the building, with a minimal reduction of visible light transmittance.
Insulating glass units are fabricated according to project specifications. IG units can be constructed using a large variety of glass products to achieve desired aesthetics, meet design criteria, safety codes and/or to improve solar control and thermal performance.
Glass options include clear, low iron, Low-E's, standard or high performance (spectrally selective) tints, reflective, silk-screened, spandrel, laminated, decorative and wired glass. The glass lites of an IG unit can be annealed, heat-strengthened, tempered or laminated.
Pictures:
Specification:
Thickness:
5+9A+5mm; 6+12A+6mm; 6+16A+6mm; 8+12A+8mm; 8+16A+8mm; etc
Max Size:
3300mm x 10000mm (except for manual production) Min Size: 180mm x 350mm
Air or argon spacer gap:
6mm, 9mm, 12mm, 15mm, 16mm etc
Glass Option:
Annealed Float glass, Low-E Glass, Tinted Glass, Reflective Glass, Laminated Glass, Tempered Glass, Silkscreened Glass etc
Glass Color:
Clear, Ultra Clear( low iron), light blue, Ford blue, dark blue, ocean blue, light gray, blue gray, light green, gold, bronze etc.
Code Compliance:
GB/T 11944 ASTM C1172 EN1279 JIS R3205 AS/NZS4666
Application:
Insulating Glass (IG) units are used in essentially all exterior building applications, including vertical glazing, sloped glazing, overhead glazing and skylights, and also in both vision and spandrel (nonvision) areas.
1. Skylight, storefront, office indoor partition;
2. Shower door, sliding door, swinging door;
3. Pool fence, balustrade, balcony;
4. Dining table, glass furniture;
5. Window, curtain wall, stairs, glass wall, glass railing;
6. Splash back, shower screen, glass floor.
Company Profile
Wallkingdon Technology was founded in early 2014 with a total investment of USD 20 million, a leading glass processor in China. Our plant covers an area of 36,000 m² and have an annual glass processing capacity of 800,000 m². Our equipment were all world advanced, such as Tamglass, Bystronic and Diptech etc.
The product line includes all kinds of architectural glass such as Laminated Glass, Multi Curved Glass, Sentry Glass Plus, Curved Glass, Tempered Glass, Insulated Glass, Low E glass and more. The decorative glass includes Casting Glass, Forested Glass, Digital printed Glass, Screen printing Glass and Engraving Glass.
Staying focused and committed all these years, we have grown into one of the renowned architectural and art glass manufacturers in Asia. We provide topnotch products and services which can exceed our customers' expectations.
Our mission is to produce both high-volume and one-off specialty glass products cost effectively and quickly,whatever your project demands from exterior high rise windows to large capacity glass for storefronts or showrooms.
With the precious inputs and creativity from designing experts, we can provide high quality glass products to the industry, allowing construction companies to have cost effective solutions while keeping quality to highest level. Our products are strictly in accordance with the standard of BS/EN, AS/NZS, ASTM,ANSI standards etc.
