Help CenterGT Air Intake Filter
Related Products
| Model No. | YTGLT-F7 S series |
|
Size Top Circular Cap (OD) Top Circular Cap’s down cut OD Top Circular Cap’s down cut Depth Top Circular Cap’s Nut Hole Filter Outer Dia Filter Inner Dia Filter Overall Length Gasket OD Gasket ID Gasket Thickness Gasket Cross Section |
234.2 mm 120 mm 60 mm ø 16 mm 235 mm 120 mm 600 ± 2 mm 224 mm 204 mm 10 mm 10mm x 10mm (Rectangle) |
| Categories of Filter | Air intake silencing equipment of complex air intake |
| Filter Efficiency | 97% |
| Air Intake Flow | 18 Kg/s |
| Air Intake Temperature |
5-450C Average 350C |
| Filter Level | ≤ 1 mg/m |
| Pressure Drop |
initial ≤ 20 Pa final ≤ 30 Pa |
| Filter Material | Compound water-proof material (Paper Type) |
| Frame Material | Q235 steel |
| No of Pleats | Min. 219 |
| Net weight | 4.65 Kg/each |
| Gross weight | 5.20 Kg/each |
| Package | Individual |
More Sizes Available:
325 x 215 x 600mm / 660mm / 800mm / 864mm / 1000mm 1320mm
350 x 245 x 600mm / 660mm / 900mm
Customized service preferred. Max. length upto 2000mm.
Filter Media:
Hollingsworth & Vose (USA), TORAY brand (Japan), Top brand of China
Air intake filtering system of gas turbines, air compressor, dust collector, sandblasting, mining industry, oxygen generation station, cigarettes factories, etc.
