PTFE Suspension Molding Powder with electrical insulation
- shanghai
- T/T
- 15 days
You May Like
Product Details
| CAS No. | 9002-84-0 |
Product Description
PTFE Suspension Molding Powder
1. Keywords:PTFE;Molding;Teflon
2. Product Introduction
The raw material is waxy white powder, average particle size is 20-40um, the melting point is 327 ± 5 ℃, and the standard specific gravity is 2.130-2.190. The product can be used stably between - 100 ℃ and 260 ℃, and has excellent heat resistance, electrical insulation and chemical permeability resistance.
3. Technical parameter
Item | Technical Index | |||
JF-4TM | JF-4TN-S | JF-4TN | ||
Cleanliness | The surface is white, the texture is uniform, and no impurities are allowed to be entrained. | |||
Tensile Strength, Mpa ≥ | 37.5 | 35.0 | 32.0 | |
Elongation at Break, % ≥ | 320 | 300 | ||
Volume density, g/L | 300~550 | |||
Average particle size, um | 30±5 | 30±10 | ||
Moisture/Water content, % ≤ | 0.02 | 0.03 | ||
Melting point, ℃ | 327±5 | |||
Standard specific gravity | 2.130~2.190 | |||
Thermal instability index ≤ | 30 | |||
4. Mark, Packing, Storage & Transportation
4.1 Mark
The packing bags (boxes) of this product should be clearly marked with firm company name, product name, batch number, brand number (specification number), net content, etc.
4.2 Package
Packed with sealed PVC bag, load in Water content proof paper barrel. The net weight is （20±0.1）kg per barrel.
4.3 Storage
It should stock in clean, cool and dry warehouse, prevent from agglomeration and contamination.
4.4 Transportation
Not classified as hazardous for transport. During transportation and storage, avoid heavy shaking, and prevent from solarization.
5. Main Application
JF-4TM:Make insulator and capacitor film, etc.It is clean and pure, can make phased film or filled turning film
JF-4TN-S: The particle size is uniform, can make filled products.Make tube, rod, plate and seal material, etc.
JF-4TN：Make tube, rod, plate and seal material, etc.
