0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter

Changsha Wencheng Electrical Equipment Co., Ltd
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter thumbnail-1
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter thumbnail-2
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter thumbnail-3
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter thumbnail-4
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter thumbnail-5
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter photo-1
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter photo-2
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter photo-3
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter photo-4
0.7kw to 150kw 220V TO 380V Voltage Frequency Transformer Changer or Converter photo-5
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2004
Product Certifications:
ISO9001
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product descriptions from the supplier
Overview

0.7kw to 150kw 220V TO 380V voltage frequency transformer changer or converter

Product Overviews

We have several kinds of frequency drive as below:

a.1ph 220V input and 3ph 220V output

b.3ph 220V input and 3ph 220V output

c.3ph 380V input and 3ph 380V output

d.3ph 480V input and 3ph 480V output

e.1ph 220V input and 3ph 380V output

f.1ph 220V input and 1ph 220V output

g.DC 300~380V/450-650V input and AC 220V/380V output solar inverter



Product Specifications

EM12 series frequency inverter is based on the accurately understanding of EMHEATER for customer’s requirements, inheriting the consistent pursuit of EMHEATER for high-quality, high reliability. EM12 series frequency inverter will bring you a new using experience with its excellent performance and powerful features.


Product Features

Feature:
1.EM12 is first class frequency inverter with very strong software and hardware.
2.It has servo drive feature, with perfect speed control mode, and excellent torque control mode.
3.It can save 2 group motor parameters , and can drive synchronous motor and asynchronous motor.
4.It has sensor-less vector control (SVC), vector control+ PG; V/F control and V/F separation control.
5.It has 49 kinds digital input functions and 38 kinds digital output functions.
6.It has S curve of acceleration and deceleration, user can self defined S curve turning time.
7.The IGBT carrier frequency can auto adjustment according to heat sink temperature.
8.35 kinds protection function, including auto detecting short circuit after power on.
9.Including textile swing frequency and skip frequency function, etc.
10.Voltage Range:220V~240V; 380V~440V.
11.Input Frequency Range:45~65Hz.
12.Output Voltage Range:0V~rated input voltage.
13.Output Frequency Range:V/F( 0~3000Hz); Vector Control (0~300Hz).
14.Overload Capacity:60s with 150% of rated current, 3s with 180% of rated current.
15.From 0.75~7.5KW Plastic house; 11~400KW is metal house.
16.Speed Accuracy: ±0.5% (SVC); ±0.02% (VC).
17.Pulse setting input: 0Khz~100Khz.
18.All model built-in RS485 card, and approved by CE.
19.EM12-G3/P3 models are integrated IGBT.
20.The malfunction ratio is 0.1% within 18 months warranty.




Feature:
1,EM12-SP MPPT algorithm of fast tracking of maximum power point of PV cells, efficiency > 99%.
2,Solar battery working point voltage can be manually or automatically MPPT tracking.
3,All-weather automatic operation, can also be manually, realize "sunrise work and sunset sleep”.
4,It can switch between city grid AC power supply and PV battery power.
5,Auto sleep function/pump dry protect/low frequency protection/ over load protection, etc.
6,Water level detection function, can support terminal and analog detection.
7,Accurate display PV power, PV current, operating parameters, such as pump flow.
8,The IGBT carrier frequency can auto adjustment according to heat sink temperature.
9,35 kinds protection function, including auto detecting short circuit after power on.
10,Suggested working Voltage Range:DC 300V~380V or DC450V~650V.
11,Controller perfect protection function, such as over voltage/over current/loss of phase.
12,Output Voltage Range:0V~rated input voltage.
13,Output Frequency Range:V/F( 0~3000Hz); Vector Control (0~300Hz).
14,Overload Capacity:60s with 150% of rated current, 3s with 180% of rated current.
15,Speed Accuracy: ±0.5% (SVC); ±0.02% (VC).
16,Pulse setting input: 0Khz~100Khz.
17,All model built-in Modbus, RS485 card, terminal control, analogy control.
18,EM12-SP models are integrated IGBT.
19,The malfunction ratio is 0.1% within 18 months warranty.


Product Tags: EM12-G3-045 , frequency inverter
