PVDF Resin For Injection Molding
- 20000 Kilogram / Kilograms per Month
- shanghai
- T/T
- 15 days
Product Details
Brand Name: | FLONMAKE | Place of Origin: | China | Model Number: | FM-025 |
Type: | Other, Chemical Grade | Purity: | 99% | CAS No.: | 24937-79-9 |
Product Description
PVDF Resin For Injection Molding
1. Product Introduction
PVDF 2320 resin is a thermoplastic fluropolymer. It has higher tensile strength and compression strength,and its abrasion resistance and stiffness are better. Its melting temperature is about 170oC,and PVDF resin has fine melting process performance. It can be easily processed with versatile process equipment by conventional methods such as compression molding extrusion and injection,etc.
Application in preparing pumps, valves, duct, lining of armor plate, film, wire insulation and profiles.
2. Main Features
Main Features | |
Excellent resistance to weathering | Ozone resistance |
Irradiation resistance | Ultraviolet high proofing |
Excellent dielectric property | Excellent corrosion |
3. Technical Parameter
Item | Test Method | Unit | 2320 |
Physical Property | |||
Physical Property | ASTM D792 | g/cm3 | 1.74~1.78 |
Thermal | / | / | / |
Melting Point | ASTM D3418 | oC | ≥165 |
(1%,N2)Thermal Decomposition | ASTM D3418 | oC | ≥390 |
Mechanical Property | |||
Shore Hardness | ASTM D 3418 | - | 70~80 |
Tensile Yield Strength | ASTM D638 50mm/min@23oC | Mpa | ≥40 |
Elongation at Break | / | % | ≥25 |
4. Mark, Package, Storage & Transportation
4.1 Mark
The packing bags (boxes) of this product should be clearly marked with firm company name, product name, batch number, brand number (specification number), net content, etc.
4.2 Package
This product is packed in paper barrels (lined with polyethylene plastic bags) with a net content of (25±0.2kg) per barrel. Each barrel shall be provided with a product certificate, including: company name, product name, batch number, brand (specification number), net content and production date, etc. In case of special packaging, the supplier and the demander shall negotiate separately.
4.3 Storage
This product should be stored in a clean, cool and dry place to prevent rain, sunshine, moisture, dust and other impurities.
4.4 Transportation
This product is transported according to non-dangerous goods. Moisture and severe vibration should be avoided during transportation.
