Spherical Aluminum Oxide Powder 20um
- Tianjin/Qingdao and other port in China
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
- 7 days
You May Like
-
Spherical Fused Alumina Micro Powder 5um 2um
-
White Aluminum Oxide Microsphere 2um 99.9% Purity
-
Black Silicon Carbide 98C F16 F20 F22 F24
-
Green Silicon Carbide 99C SiC Grit F30 F36 F40 F46 From China
-
ZrA Zirconia Aluminium Oxide Grain F8 F12 F14 F16 F20
-
Normal Aluminium Oxide Brown Abrasive Grain F30 F36 F40 F46 F54
Product Details
| Brand Name | Haixu Abrasives | Place of Origin | China | |
| Model Number | 20um | Material | alumina oxide | |
| Usage | thermal conductive | Abrasive Grain Sizes | 20um |
Product Description
Spherical Aluminum oxide powder 20um
Description:
Spherical alumina powder is produced from low soda aluminum oxide aluminum oxide by fire fusing process. The sphere shape leads to low BET surface area and high flowability. In the meantime, spherical alumina powder is of high thermal conductivity and low oil absorption rate. It is widely used as thermal conductive filler in electronics, expoxy resin, thermal insulating media in ceramic sintering, thermal spaying powder, etc.
Characteristic:
1. High Al2O3 purity more than 99.9%. Low Na2O content less than 0.1%.
2. High spherical rate, good flowability without damage for grinding.
3. Low oil absorption rate make it suitable for filler material.
4. Low BET surface area and low Viscosity mixed with resin.
5. Higher thermal conductivity than angular aluminum oxide.
Items | BET(m2/g) | Specific Gravity(g/cm3) | conductivity (us/cm) | PH | Moisture (%) | Roundness (%) | D10 Value(um) | D50 Value(um) | D90 Value(um) |
HGSA01 | 1.69 | 3.71 | 6.07 | 7.79 | 0.03 | 98 | 0.58 | 1.03 | 2.14 |
HGSA02 | 1.27 | 3.72 | 5.40 | 7.70 | 0.03 | 96 | 0.69 | 2.18 | 5.24 |
HGSA05 | 0.36 | 3.74 | 5.65 | 7.90 | 0.03 | 98 | 2.54 | 5.52 | 9.09 |
HGSA10 | 0.17 | 3.76 | 4.05 | 7.62 | 0.03 | 98 | 4.18 | 10.03 | 18.46 |
HGSA15 | 0.14 | 3.86 | 1.83 | 7.80 | 0.03 | 98 | 7.03 | 15.11 | 24.06 |
HGSA20 | 0.11 | 3.80 | 6.87 | 7.80 | 0.03 | 98 | 10.5 | 20.8 | 37.24 |
HGSA30 | 0.10 | 3.76 | 7.95 | 7.40 | 0.05 | 96 | 16.88 | 30.52 | 48.87 |
HGSA40 | 0.07 | 3.81 | 4.65 | 7.45 | 0.03 | 98 | 23.77 | 41.54 | 66.44 |
HGSA70 | 0.05 | 3.87 | 6.18 | 7.70 | 0.03 | 96 | 44.32 | 71.54 | 106.5 |
HGSA90 | 0.06 | 3.88 | 8.15 | 7.35 | 0.05 | 95 | 55.23 | 87.96 | 134.92 |
HGSA120 | 0.06 | 3.82 | 2.60 | 7.46 | 0.03 | 96 | 90.95 | 122.39 | 172.72 |
Typical Chemical Composition
Items | Guarantee Value | Typical Value |
Al2O3(%) | 99.9 | 99.94 |
SiO2(ppm) | 500 | 373 |
Fe2O3(ppm) | 200 | 120 |
Na2O(ppm) | 200 | 107 |
Application:
1. Fillers for semiconductor sealing materials
2. Various resin filling materials. Especially suitable for improving the thermal conductivity and surface hardness of silicone rubber, epoxy resin, various engineering plastics, etc.
3. Setting powder for ceramic sintering
4. Grinding and polishing
5. Thermal spraying materials
