 CSYHT SD1 Fusion Splicer 6 Motors Heating Shrinkting Fiber Optical Machine Fiber Fusion Splicer





Product Description





Product features

Low loss

Optical fiber adjustable core cladding alignment and lower loss.

New appearance

This optical fiber fusion splicer is novel in appearance design, Horizontal integrated design with display screen.

Touch screen operation

The 5.0 " HD touch screen is simple and flexible to operate.

Preheating function

It has a preheating function, and the preheating starts automatically after the windproof cover is closed.

High power lighting lamp

The design of high-power double illumination lamps facilitates night work and makes it easier to place optical fibers.

Multifunctional fixture

The three-in-one optical fiber clamp is suitable for various optical fibers.

Support time, battery power display

This product can check the time and battery level at any time.

Removable battery

This product comes standard with 5200mAh battery, which can complete welding and heat cycle 200 times.

Counting function

This product supports fusion records and fusion image counts, which is convenient for storage and query.

Dust self-test

This product supports dust inspection in CMOS calibration, which is used to detect the position and size of dust.

Thick cushioned rubber armor is dustproof, dropproof and shockproof.

There are 10 languages and multilingual settings, covering the global market.

Two LED lighting lights at the front of the fuselage are convenient for construction in dark environments.





Specification

Model

SD1

Size

222(L)x 140(W)x 137.5(H) mm

Weight

Host:1.63kg   battery:0.34 kg     Weight:1.97kg

Alignment method

Core to core

Motor

Six Motors

Applicable cores

single core

Applicable fiber

SM(ITU-TG.652 & G.657)/MM(ITU-TG.651)/DS(ITU-TG.653)/NZDS(ITU-TG.655)

Diameter of fiber

0.25~3.0mm/FTTH Fiber

Fiber cleaved length

Coating:0.125~1mm/Cleaved length:8~16mm

Splicing program

Auto focus, core to core alignment

Typical splice loss

SM:0.02dB/ MM:0.01dB/ DS:0.04dB/ NZDS:0.04dB/ G.657:0.020dB(ITU-IT Standard measured by shearing method)

Return loss

>60dB

Illumination

2 LED lights (optical fiber lighting and external environment lighting)

Splicing time

Standard 8s

Splicing loss evaluation

Available

Splice length

20~60mm

Tube heating time



Standard Heating or Preheating mode,typical heating time 20 seconds, which can be customized according to the external environment

Splicing record

More than 8000 sets of fusion record storage space

Storage of splice result

100 group images

Tensile test

Standard 2N

Operating condition

Altitude:0~5000m,Humidity:0~95%,-20~50℃,Wind max:15m/s

Storage temperature

Humidity: 0~95%,-40~80℃,

Display

90-degree dual camera, 5-inch touch screen

Fiber magnification

300X(X or Y view), 150X(X and Y view)

Power supply

Input:AC100~240V,output:DC13.5V 10A

Remaining power display

Available

Battery capacity

5200mAh, typical 260 times(splice + heat), power supply time≤3h

Operation method

Touch screen and button

Communication port

MINI USB



System Setting

No.

Icon name

Key function

1

Parameters

According to the type of optical fiber, choose the appropriate fusion mode or customize the fusion mode.

2

Fusion Splicer

Enter the fusion state.

3

Arc Cali

Correct the discharge parameters of the machine.

4

Motor Adjust

Adjust the propulsion motor and core adjusting motor, please operate under the guidance of professionals.

5

Heat setting

Adjust heat parameters, temperature, time, etc.

6

Tools

The system setup includes display brightness level, CMOS adjustment and other functions. Except for brightness level, other functions are recommended for users to operate under the guidance of professionals.

7

Data Storage

Check the fusion record.

8

Time Setup

Adjust the machine time.



CSYHT SD1 Fusion Splicer 6 Motors Heating Shrinkting Fiber Optical Machine Fiber Fusion SplicerCSYHT SD1 Fusion Splicer 6 Motors Heating Shrinkting Fiber Optical Machine Fiber Fusion SplicerCSYHT SD1 Fusion Splicer 6 Motors Heating Shrinkting Fiber Optical Machine Fiber Fusion SplicerCSYHT SD1 Fusion Splicer 6 Motors Heating Shrinkting Fiber Optical Machine Fiber Fusion SplicerCSYHT SD1 Fusion Splicer 6 Motors Heating Shrinkting Fiber Optical Machine Fiber Fusion Splicer
