Home > Products > SD Mobile DVR > 4 Channel 4G Lte Live Video Stream GPS Tracking Mobile Car DVR
4 Channel 4G Lte Live Video Stream GPS Tracking Mobile Car DVR
- 5000 Piece / Pieces per Month
- Shenzhen Port
- T/T PayPal Cash
- 3 days
- 4 Channel 1080P Car Vehicle CCTV Camera System Mobile DVR
- 4 Channel HD Mobile DVR 1080P Public Bus Truck Mdvr GPS 3G 4G Mobile DVR
- Vehicle Mobile DVR 720p 4CH HDD/SSD with GPS 3G 4G G-Sensor Wi-Fi
- 1080P Full SD Real Time Monitor Parking Recording 4 Channel Mobile Car DVR
- Factory Wholesale OEM Wireless Monitoring Mobile Mdvr Bus Car Truck Smart CCTV 4G GPS DVR
- 8channel WiFi 4G HDD GPS CCTV Mobile DVR for Fleet Management
Product Details
Brand Name: | Sodimax | Place of Origin: | China | Model Number: | SDM618-4G-GPS |
Product Description
It is a small device but we increase passenger and driver safety and independently record any traffic collisions - it is no longer your word against theirs.
The Black Box Recorder has been developed to keep peace of mind for both the driver and the passenger.
Our small and compact device protects drivers and passengers from:
FenderBender - one word against another equals quick insurance settlements
Accusations and cab rage - one of the quickest ways to loss of livelihood for the driver
Passenger security - Make your taxis a safer environment for all
Difficult insurance claims with your word against theirs
Features
1) SD card for storage,max 2*512G
2) GPS tracking and 3G remote control realtime monitoring optional
3) UPS technology to protect sudden power off
4) The Power and mainboard are integrated with much better quality
5) G-sensor ,RS232/485 interface,RJ45 lan port,6ch alarm input
6) Mini size and light on weight
7) World class anti-vibration technology for over 8 years lifetime
8) High end products for Military dep or government usage
Specifications
Item | Description | |
OS | Linux | |
Graphics Operation Interface | System parameters can be set through external display and remote controller | |
Security Management | 2-level management for user password, administrator password, supporting encrypted transmission | |
Video and Preview | Video Input, Output | 4-channel video input, 1channel video output; 1.0Vp-p, 75Ω |
OSD | Character superposition function, information superposition of time and date, device ID and GPS, etc. | |
Video Compression Format | Compression coding. Applying Hisilicon hi-performance processor. | |
Dual-Stream | Supported | |
Preview Function | Preview of 1-channle, 4-image stitching, supporting full screen triggered by event and switching of stitched images | |
Frame Rate | PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel | |
Resolution | CIF, HD1 and D1 for selection, max 4*720P | |
Quality | Grade 1 to grade 5 for selection (descending) | |
Bit Rate | CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection | |
Audio | Audio Input, Output | 4-channel input, 1-channel output |
Compression Format | G.726 coding | |
Recording | Storage Medium | Supporting dual SD card, which supports up to 512G |
File Format/ System | ASF/FAT32 | |
Video Strategies | Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording | |
Video Search | Searching by time, type, storage device and other conditions | |
Video Playback | Supporting playback on local device, supporting synchronous playback of up to 4 channels and analysis on vehicle information in the files | |
Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time | ||
Alarm | Alarm Input/ Output | 6-channel on/off signal alarm input, 1-channel on/off signal alarm output |
Alarm Recording | Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30min | |
Storage Space Alarm | Supporting settings for alarm of storage space | |
Function Alarm | GPS overspeed alarm, acceleration alarm, motion detection alarm | |
Communication Ports | RS232, RJ45 10M/100M self-adaptable network interface | |
Wireless Transmission (Optional) | Embedded 3G wireless transmission module, WCDMA, CDMA2000, TD-SCDMA system for selection; Compatible with GPRS, EDGE; Embedded Wi-Fi module; | |
GPS (Optional) | Supporting external GPS | |
Remote Data Transmission Channel Selection | Supporting 3G, Wi-Fi data channel transmission, supporting Wi-Fi priority transmission strategy; supporting remote downloads of back-end recording strategies; | |
PTZ Control | Supporting PTZ control realized by local ad client software; | |
Parameter Configuration | Supporting parameter configuration functions for mobile DVR coding channel; | |
G-Sensor | Embedded | |
System Upgrading | Supporting SD card and remote upgrading | |
Power Supply and Power Consumption | Power Supply | 1. ACC on/off 2. Delayed shutdown 3. Timed on/off |
Input Voltage | DC:+8V ~ +36V | |
Output Voltage | +12V@4*0.5A; +5V@0.5A | |
Power-off Protection | With patented UPS power supply continuous working technology, it can work for 3~5 seconds after external power supply is cut so that the intactness of video data can be kept upon sudden power failure | |
Power Consumption | <10W in normal operation; <0.5W in standby mode | |
Operating Environment | Temperature | Normal: 0℃ ~ +60℃; upon hard drive preheating: -25℃ ~ +60℃ |
Humidity | 10% to 95% | |
Dimensions | 141(L)×133(W)×43(H)mm |
RFQ
1.
Q: Does the MDVR support Hard drive and SD card?
A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD card.
The storage capacity can be from 32GB to 2TB.
2.
Q: Is it difficult to install MDVR into the vehicle?
A: Actually it is easy to install it into vehicle. Most driver can figure out how to connect the power cables.
And the camera installation is more easy. Just screw, connect and mount on the target place inside the vehicle.
3.
Q: If I need door open and close alarm, overspeed alarm, reverse video, brake video, left-turn video, right-turn video, etc,
is it available?
A: Definitely yes!
The I/O RS232 and 485 extension port is for all expanded purposes, including the functions above.
In fact, there are more customized functions which can be connect through this port, such as Fuel sensor, Counter system,
PTZ camera, and so on.
4.
Q: We have our own platform and server, can we use your MDVR? Do you have SDK or can you do customized platform for us?
A: Yes, we have SDK ready and welcome your OEM customized order!
