Laboratory Mini Spray Dryer 1500-2000ml Mini Milk Powder Making Machine Vacuum Centrifuge Drying Machine

Shanghai Genyond Technology Co., Ltd.

2Yrs

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Trading Company

Year Established:

2013

Factory Size:

Below 1,000 square meters

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Finished Products

food products include milk powder, tea powder, cocoa powder, coffee powder, soybean flour, wheat flour, and chili powder

Family Overview

LPG High Speed Centrifugal Spray Dryer

Specification	Air Inlet temperature	Air exhaust temperature	Nominal water evaporation capacity (Kg / h)	Heating method	Drying tower diameter (mm)	Overall Dimensions (m)	Product yield
LPG-5	140-550 ° C	60-120 ° C	5	1. High-pressure steam 2. steam + electricity 3.any kinds of fuel diesel, natural gas, liquefied petroleum gas or coal, etc 4. solid fuel any combustible material	1100	2×1.4×2.2	95-99.9% depend on the properties of the product and configurations
LPG-25			25		1800	5×3×4
LPG-50			50		2150	6×4×5
LPG-100			100		2560	8×4×6
LPG-150			150		2860	8×5×7
LPG-200			200		3200	10×5×8
LPG-300			300		3600	Design as per configuration of the plant and URS
LPG-500			500		4300
LPG-600			600		4500
LPG-750			750		5000
LPG-1000			1000		6000
LPG-2000			2000		7600
LPG-3000			3000		8500
LPG-5000			5000		10000
LPG-8000			8000		13000
LPG-10000			10000		14500
LPG-12000			12000		16000
LPG-15000			15000		18000

YPG pressure spary dryer

Specifications	Air Inlet temperature	Air exhaust temperature	Nominal water evaporation capacity (Kg / h)	Heating method	Drying tower diameter (mm)	Overall Dimensions (m)	Product yield
YPG-25	140-550 ° C (depend on the product to be dried, and URS)	60-120 ° C (depend on the product to be dried, and URS)	25	High-pressure steam, or steam + electricity, or any kinds of fuel (diesel, natural gas, liquefied petroleum gas or coal, etc.), or solid fuel (any combustible material). Please specify.	1200	5×4×12	95-99.9% depend on the properties of the product and configurations
YPG-25			50		1400	6×4×13
YPG-25			100		1600	6×4×15
YPG-25			150		2200	8×4.5×19
YPG-25			200		2600	10×5×20
YPG-25			300		3200	12×6×22
YPG-400			400		3500	Design as per configuration of the plant and URS
YPG-500			500		3800
YPG-600			600		4100
YPG-750			750		4500
YPG-1000			1000		5500
YPG-2000			2000		7300
YPG-3000			3000		8000
YPG-5000			5000		10000
YPG-8000			8000		13000
YPG-10000			10000		14500
YPG-12000			12000		15800
YPG-15000			15000		17500
YPG-18000			18000		19000
YPG-20000			20000		20300
YPG-23000			23000		21800
YPG-25000			25000		22800
YPG-28000			28000		24000
YPG-30000			30000		25000

QPG Air StreamSpray Dryer

Specifications	Air Inlet temperature	Air exhaust temperature	Nominal water evaporation capacity (Kg / h)	Heating method	Compressed air pressure (MPa)	Compressed air consumption (m³/min)	Heat required (KCal/h)	Power of Fan (kw)	Yield of product
QPG-5	140-550 ° C (depend on the product to be dried, and URS)	60-120 ° C (depend on the product to be dried, and URS)	5	High-pressure steam, or steam + electricity, or any kinds of fuel (diesel, natural gas, liquefied petroleum gas or coal, etc.), or solid fuel (any combustible material). Please specify.	0.4	0.9	1	0.75	95-99.5%, depend on the properties of the product and configurations
QPG-25			25		0.6	0.9	5	4
QPG-50			50			1.1	10	7.5
QPG-100			100		0.7	1.5	20	11
QPG-150			150			2.7	30	15
QPG-200			200			3.4	40	18.5
QPG-500			500		0.7	7.5	100	45
QPG-1000			1000		0.7	1.4	200	90
QPG-1500			1500		0.7	2	300	125
QPG-2000			2000		0.7 0.7 0.7	2.5	400	160
QPG-5000			5000			5	500	380
QPG-10000			10000			9	1000	700

ZPG Spray Dryer

Specification	Air Inlet temperature	Air exhaust temperature	Nominal water evaporation capacity (Kg / h)	E x t r a c t P r o c e s s i n g Capacity (Kg/h)	Output (Kg/h)	Feeding Solid contents (%)	Final moisture contents (%)	Heating method
ZPG-5	140-220 , adjustable	60-100 , depend on the product properties and processing requirement	5	5.59-9.5	0.59-4.5	10-45	3-5%	High-pressure steam, or steam + electricity, or any kinds of fuel (diesel, natural gas, liquefied petroleum gas or coal, etc.), or solid fuel (any combustible material). Please specify.
ZPG-25			25	27.9-47.5	2.9-22.5
ZPG-50			50	55.9-95.0	5.9-45.0
ZPG-100			100	111.7-190.0	11.7-90.0
ZPG-150			150	167.6-285.0	17.6-135.0
ZPG-200			200	223.5-380.0	23.5-180.0
ZPG-300			300	335.0-570.0	35.0-270.0			High-pressure steam, or steam + electricity, or any kinds of fuel (diesel, natural gas, liquefied petroleum gas or coal, etc.), or solid fuel (any combustible material). Please specify.
ZPG-500			500	558.8-950.0	58.8-450.0
ZPG-800			800	894.1-1520	94.1-720
ZPG-1000			1000	1117-1900	117-900
ZPG-1200			1200	1341-2280	141-1080
ZPG-1500			1500	1676-2850	176-1350
