Plate Milk Pasteurizer for Fresh milk Yogurt Cheese
Plate pasteurizer is used for processing milk,then go to fermentation and do cheese,this is a necessary process for cheese work.It connects with separator, homogenizer, flash evaporator and degasser etc. equipment.
Features:
- Working capacity can be customized, with wide experienced technical service engineer team;
-The pasteurization temperature can be designed based on client requirements;
-Full automatic control: UK Spirax Sarco steam pressure reduce valve, German Labom temperature transducer, Anthone temperature recorder without paper, Italy hot water pump; Simens PLC full-auto control with colorful touch screen, the precision of temperature control is ±0.5 degree;
-Semi-auto control: UK Spirax sarco steam pressure reduce valve, German Burkert or spirax sarco temperature control system, recorder without paper, Italy hot water pump, Siemens control , the precision of temperature control is ±0.5 degree;
Working Capacity:
500L/H to 30T/H , design based on client requirement;
Technical Parameter:
Technical parameters: 5℃→65℃(homogenization) →85~95℃(15S) →5℃
Production capacity: 500L-20T/H
Control type: Full-automatic control (PLC with touch screen),Semi-auto PID Control.
Standard attachments:
A. Plate heat exchanger;
B. Product balance bucket;
C. Hot water system;
D. Imported Hot water pump;
E. Product conveying pump;
F. Electrical control system, temperature control and recorder;
G. Stainless steel pipes and valves etc
|
Model |
Process capacity |
Heat exchanging area(m2) |
Power(kw) |
Steamconsumption(kg/h) |
External dimension(mm) |
Total weight of machine(kg) |
|
GY16-3-0.5 |
0.5 t/h |
5 |
5.2 |
52 |
1200×1200×1500 |
790 |
|
GY16-3-1 |
1 t/h |
8 |
5.2 |
60 |
1500×1500×1800 |
880 |
|
GY16-3-2 |
2 t/h |
13 |
6 |
104 |
1800×2000×1800 |
980 |
|
GY26-3-3 |
3 t/h |
20 |
6 |
156 |
2000×2000×2200 |
1080 |
|
GY26-3-4-5 |
4-5 t/h |
30-45 |
8 |
260 |
2250×2000×2200 |
1250 |
|
GY26-3-6-8 |
6-8 t/h |
35-50 |
8 |
400 |
2250×2000×2200 |
1250 |
|
GY26-3-10 |
10 t/h |
60 |
11 |
520 |
2800×2000×2200 |
1650 |
|
GY35-3-15 |
15 t/h |
75 |
15 |
780 |
3000×2200×2200 |
2150 |
|
GY35-3-20 |
20 t/h |
80 |
18 |
945 |
3300×2200×2200 |
2350 |
More informations:
