industrial apple chips making machines
- 1000 per Month
- T/T Credit Card
You May Like
-
full stainless steel dried apple chips making machine/fruit washing peeling slicing drying machine
-
high quality industrial banana chips machine/dry fruit industrial banana chips making machines
-
completeindustrial apple chips making machines
-
small capacity fruit and vegetable industrial dryer
-
fruit and vegetable dehydrator machine
-
shanghai dryer machine for drying mango
Product Description
mango processing line craft flow
Fresh apple → washing → peeling →cutting / pit removing → slicing → drying →cooling →packing
sliced apple chips processing craft flow
1) fresh mango →washing →peeling&pit removing →slicing →sugar soaking →drying →cooing →packing
2) first drying type →sugar soaking →drying →cooling →packing
sliced apple drying have two types machine
one is the hot air drying machine/box, the other is the belt type machine, genyond machine have expirence in the fruit and vegetable drying machines.
bellw as the hot air box/machine introduce:
Universal hot air circulation oven drying equipment belongs to adapt to a wide face, is widely used in heating the pharmaceutical, chemical, food, light industry, heavy industry materials and products, curing, drying dehydration. Such as: raw material medicine, medicine, Chinese Herbal Medicine, powders, granules, powder, the size of the pill bottles, pigments, dyes, dehydrated vegetables, dried fruit, sausages, plastic resin, electric elements, drying varnish and so on.
Features of hot air drying machine
1,hot air circulation oven wide scope, can dry various materials, is a common drying equipment.
2,Most of hot air inside the loop, high thermal efficiency, energy conservation.
3,use of forced ventilation box with adjustable air board, uniform drying, heat source can be steam, oil, electricity, hot water, far infrared, etc., a wide choice.
4,hot air circulation oven temperature to adapt to a wide range, according to user requirements, up to room temperature to 350 ℃.
5,small hot air circulation oven machine noise, smooth operation, temperature-controlled, easy installation and maintenance.
model of hot air drying machine
| model | capacity | power(kw) | gas consumption | square (m2) | wind (m3/h) | temperature (℃) | tray | size(mm) |
GCT-C | 60/batch | 0.45 | 15 | 15 | 4510 | ±2 | 24PCS | 1450×1200×2000 |
GCT-1 | 100/batch | 0.45 | 20 | 23 | 4510 | ±2 | 48PCS | 2350×1200×2000 |
GCT-2 | 240/batch | 0.45×2 | 40 | 48 | 9020 | ±3 | 96PCS | 2350×2200×2200 |
GCT-3 | 360/batch | 0.45×3 | 60 | 72 | 13530 | ±4 | 144PCS | 3310×2200×2000 |
GCT-4 | 480/batch | 0.45×4 | 80 | 96 | 18040 | ±5 | 192PCS | 4300×2200×2270 |
this drying machine is processing batch by batch, if you need the continuous processing , the belt type drying machine(click here) will be you requirement.
1. We will assemble and test the machine before packing,and provide English manual.
2. If customer need, our engineers for assembling and training of workers.
The buyer shall bear the engineers round trip tickets fees, basic accommodation and Transportation,the allowance shall be paid by buyer.
3 we are factory
4.what capacity do you want. and we provide both half automatic and full automatic machines
5. pls tell me detail functions of machine , so that we can recommend the best quality and the best price machine for you.
Company Profile
Shanghai Genyond Technology Co., Ltd. is a manufacturer of extracting unit and fruit & vegetable processing line with well-equipped testing facilities and strong technical force.With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in food and beverage and other industries.Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
