Automatic sugarcane juice making machine



Product Description

Standard 3-in-1 monoblock for PET bottles rinsing, hot filling and capping. It is applicable to fruit juice, tea beverage, functional beverage, etc with 2000-20000BPH capacity. According to the special production condition, another sterilizing rinsing module could be added, that is 4-in-1 monoblock. The system has fully considered the beverage's characteristics (such as the frothing of the tea drink and mixed juice) and the technical requirement of the hot filling.
1.Full filling to avoid the bottle from sinking after the bottle cooling off, and to decrease the dissolved oxygen to the utmost extent.
2.Reasonable structured storage hopper and material supply system make the material in constant flow speed, constant pressure without frothing. Usually high position tank is adopted.
3.The storage hopper has the characteristic of gas discharge, full sealing and temperature detecting. In moderate and high speed production line, the material distributor replaces the big liquid tank to realize the complete CIP.
4.Sanitary filling head system is of umbrella structure, high filling speed.
5.Perfect filling temperature control system.
6.Reflux tank system has the function of supplying the material automatically.
7.Perfect CIP system.




Techinical Parameters

Model GY-14 GY-18 GY-24 GY32
Capacity(500ml) 4000 7000 10000 14000
Suitable bottle Diameter 50-110 ; height 150-360
Air pressure 0.7 MPa 0.7 Mpa 0.7 Mpa 0.7 Mpa
Gas consumption 1m3/min
Total power(Kw) 3.13 3.84 4.1 5.6
Total size (mm) 2250×1640×2100  2430×1800×2100 3050X2060X2100 4050×2300×2100
Total weight(KG) 2500 3000 4000 5000

Model GY-50 GY-60 GY-72 GY-80
Capacity(500ml) 24000 28000 32000 36000
Suitable bottle Diameter 50-110 ; height 150-360
Air pressure 0.7 Mpa 0.7 Mpa 0.7 Mpa 0.7 Mpa
Total power(Kw) 10.8 11 11 15
Total size (mm) 4720X3550X2750 4800X3600X2750 5800x4650x2570 7228×5300×2750
Total weight(KG) 8500 9000 9500 11000





Detailed image

Automatic sugarcane juice making machineAutomatic sugarcane juice making machineAutomatic sugarcane juice making machineAutomatic sugarcane juice making machine







Packaging & Shipping

1.Package: wooden cases for sea transportation

2.Delivery time: 30 working days after receiving the deposit

3.Installation : engineers available for installation and training overseas

4.Guarantee : 12 months after it is sent out
