Home > Products > fruit & vegetable processing machine > Commercial automatic Mango Peeling Machine
Commercial automatic Mango Peeling Machine
- T/T Credit Card
You May Like
-
High Efficiency Avocado Peeling Machine Fruit Peeler Machine with Best Price
-
Stainless Steel Apple Persimmon Peeling Machine
-
Kiwi Fruit Sorting Machine/Kiwi Weight Grading Sizing Equipment
-
Orange sorting machine apple grading machine
-
Blueberry Sorting Machine Cherry Orange Grading Machine
-
Professional French Fry Potato Cutting Machine/Cutter/Slicer for Sale
Product Description
Commercial Mango Peeling Machine/Mango Peeler Machine/Mango Skin Removing Machine
Introduction:
1. The Machine is used to peel oranges,apples and other fruit and vegetable.With high peeling rate,it is suitable for various shapes of fruit and vegetable.It is multifunctional with six functions together,includes peeling,ends cutting,coring,slicing,separation and color protecting.It is also applicable to 20 kinds of fruit and vegetable includes kiwi, pear, persimmon, citrus, lemon, kohlrabi, mango, avocado, grapefruit, guava,etc.
2. This machine can figure out fruit height and diameter automatically,so it adopts well to irregular-shaped fruits.Paring knives can automatically track changes in fruit shape and thus causing little fruit damage.The main material of the whole machine frame is high quality stainless steel,wholly computer-controlled,PLC and other electronic components are products of Japan Omron.This product has won European CE certificate. It is essential for fruit and vegetable processing.
Structure and Principle:
The equipment is consist of many parts,including outer shell,body frame,fruit bases,fruit passing fork,conveyor,fruit setting bases,main motor,paring knife,end cutter,coring knife,PLC,touch screen and other parts.It is able to peel,cut ends,core,slice at the same time or separately.It fits fruit diameter and height automatically,and the peeling thickness is adjustable.
Firstly,choose fruits according to diameters,eliminate super high,super soft and super smallfruits,sample 1-3 fruit ready to peel,then start the equipment to determine the thickness ofpeeling and ends cutting.Regulate all the actuators,set up actions and parameters.Put fruit one by one,right into the fruit bases,then they can be peeled,cut ends,cored.Finally fruit pulp,skin,end skin and cores go out from three separate holes.
Main Technical Parameter:
Overall dimension | 1700*855*1700mm |
Weight | 320kg |
Output | 13 pcs/min |
The output: take orange,apple for example,adjust for specially shaped fruit and vegetable according to actual output,with the condition of optimum peeling effect,such as kohlrabi.
Other Details:
1.Package: wooden cases for sea transportation
2.Delivery time: 30 working days after receiving the deposit
3.Installation : engineers available for installation and training overseas
4.Guarantee : 12 months after it is sent out
Company Profile
Shanghai Genyond Technology Co., Ltd. is a manufacturer of extracting unit and fruit & vegetable processing line with well-equipped testing facilities and strong technical force.With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in food and beverage and other industries.Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
