Working principle of mango fruit grading machine
Machine consists of frame, reducer, reducer casing, sprocket cover, conveyor chains, roll bars, a hopper, tighten the screw, tighten the baffle, drive shaft, driven shaft, driven sprocket, active sprocket, reducer sprocket components. After the material into the machine, under the action of gravity, the raw material self monolayer paved surface of the roller bar and kept in contact, due to the rolling of the staves, and the following non-metallic tracks, so that the roller bar in the revolution (horizontal movement) while also working surface for the same direction of rotation, the material that is in constant rotation, to the material is moved to the next process operatives can be substandard fruits and vegetables in the material movement during detection, in order to guarantee the quality of the fruits and vegetables. The machine can also be bad fruit belt conveyor program according to the user's requirements for the design of transport.
Main technical parameter of mango fruit grading machine
Model | Capacity(T/h) | Power(KW) | Dimension(mm) |
GY-20 | 15-20 | 1.1 | 8000×1400×900 |
GY-10 | 8-10 | 0.75 | 6000×1000×900 |
GY -5 | 4-6 | 0.55 | 4000×850×900 |
GY -3 | 1-3 | 0.55 | 3000×700×900 |
