basil essential oil extraction machine extractor essence distiller distillation equipment extracting plant

Name: basil essential oil extraction machine extractor essence distiller distillation equipment extracting plant
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Product Introduction

The essential oil steam distillation unit uses distillation technology and chemical separation,which can extract plant components efficiently by steam distillation,and have good effect in collecting essential oil from plants.

The material information

Plant leaves and flowers: roses, osmanthus,chrysanthemum,lavender,
sagebrush, rosemary, wintersweet, sophora japonica, mint, thyme,etc.
Plant roots: aloes, ginger, aloe, clove,etc.
Plant fruit, passion fruit, castor, aniseed, grape seeds, etc.

Processing flow

Machine picture

Parameter

Small & Medium size Essential Oil Distiller (Electricity or steam)

Model

Capacity

Power

Diameter of Condenser

Material

Heating Area of Extraction Tank

Condensing Area
of Condenser

GYC10

10L

4KW

102mm

SUS304

0.3M2

0.7M2

GYC20

20L

4.5KW

102mm

SUS304

0.4M2

0.75M2

GYC30

30L

5KW

133mm

SUS304

0.45M2

0.8M2

GYC50

50L

11KW

133mm

SUS304

0.5M2

0.85M2

GYC100

100L

15KW

133mm

SUS304

1.05M2

0.95M2

GYC150

150L

17KW

133mm

SUS304

1.45M2

1.25M2

GYC200

200L

20KW

133mm

SUS304

1.85M2

1.50M2

HEC300

300L

25KW

133mm

SUS304

1.95M2

2.00M2

Large Customized Machines (steam )

Model

Capacity

Temperature display

Cooling water circulation pump

Crane system

Console

Boiler

GYC500

500L

Digital temperature control system,
with steam stop valve,drain valves, steam traps,
etc.

Cooling water
circulation pump, 20tons/H, the
cooling water through
the pipe into the condenser

750kg

Carbon steel rust treatment table

The gas coal electric boilers

according customer local conditions to select

GYC1000

1000L

1000kg

GYC1500

1500L

1000kg

GYC2000

2000L

1000kg

GYC3000

3000L

1500kg

GYC4000

4000L

2000kg

GYC5000

5000L

2000kg

Structure: A: up charging and up discharging (Crane system needed)
B: up charging and side discharging
C: up charging and bottle discharging
