AXIS FA54 Main Unit

AXIS FA54 Main Unit

High-performance multi-view surveillance with Forensic WDR

Full frame rate HDTV 1080ps streams from four sensor units

Forensic WDR

Quad view stream, Axis Zipstream and Corridor Format

HDMI output, two-way audio, four configurable input/output ports

Two microSD card slots

Technical specifications

DOWNLOAD DATASHEET ON PRODUCT SUPPORT PAGE

Models: AXIS FA54 Main Unit

Camera

Image sensor –

Wide dynamic range Forensic WDR

Min illumination/ light sensitivity (Color) –

Min illumination/ light sensitivity (B/W) –

Thermal sensitivity (NETD) –

Thermal sensor resolution –

Video

Max video resolution 1920x1080

Max frames per second 25 / 30

Day and Night functionality –

Electronic image stabilization –

Multiple color palettes –

Lens

Focal length - mm

Varifocal lens No

Aperture -

Horizontal field of view - °

Vertical field of view - °

Lens mount –

Replaceable lens –

Compression

Zipstream

Yes

H.264 Baseline, High, Main

H.265 –

Motion JPEG

Yes

Audio

Audio Support

Yes

Two-way audio

Yes

System integration

Audio detection

Yes

Active tampering

Yes

Alarm inputs/outputs 4

Serial connectors –

AXIS Camera Application Platform

Yes

Digital I/O

Yes

Network

Power over Ethernet –

PoE Class –

Security

HTTPS encryption

Yes

IEEE 802.1X

Yes

General

Built-in IR –

Local storage (memory card slot)

Yes

Operating temperature 0 to 45 °C

Outdoor Ready –

Vandal rating –

IP rating –

Power

Power (max) 30.0 W

Power (average) 14.0 W

DC input voltage 12 V

AXIS FA54 Main Unit Sensor units

AXIS FA1105 Sensor Unit

Highly discreet indoor surveillance in 1080p

AXIS FA1125 Sensor Unit

Extremely discreet indoor surveillance in 1080p

AXIS FA3105-L Eyeball Sensor Unit

Discreet indoor 1080p surveillance with IR

AXIS FA4115 Dome Sensor Unit

Flexible, discreet indoor 1080p varifocal dome

Part number for ordering

NAME AXIS REGION PART NUMBER

AXIS FA54 Main Unit AU 0878-006

AXIS FA54 Main Unit KR 0878-007

AXIS FA54 Main Unit US 0878-004

AXIS FA54 Main Unit JP 0878-005

AXIS FA54 Main Unit AR 0878-008

AXIS FA54 Main Unit CN 0878-009

AXIS FA54 Main Unit EU 0878-002

AXIS FA54 Main Unit UK 0878-003

AXIS FA54 Main Unit BR 0878-012

AXIS FA54 Main Unit IN 0878-113
