1. The telescopic belt conveyor is mainly composed of fixed frame, movable frame, hydraulic mechanism, synchronous telescopic thrust structure, belt conveying structure, protective rod mechanism and control system.
2. The front end of the telescopic belt machine is provided with a crushing-resistant section for unloading, and the length of the unloading drum is not less than 500mm, which is built into the telescopic machine and the cylinder surface is galvanized.
3. The front button has a protective baffle, which can effectively protect the button and prevent the button from being damaged when the belt conveyor is telescopic.
4. The fuselage is made of high manganese steel for added strength.
5. The front end is equipped with night work lights.
6. Conveying speed: 25-45 m / min, frequency conversion adjustable.
7. The telescopic belt machine is equipped with hydraulic lifting system, which is controlled by solenoid valve, and the conveying inclination angle is 1°- 5°. The horizontal and fixed inclination angle is controlled by either side of the handle of the telescopic machine.
8. With forward and reverse transmission function, forward and reverse switching separate control, smooth transition.
