IS220PAICH1B Input output package

Italian Ruiao REER input extension control module MOSAIC MI8 1100020

Product Overview:

Additional input unit

8 digital inputs, 4 test outputs

Safety level: PL e

Safe input: 8 digital inputs

Safety level (SIL/PL): SIL 3- SILCL 3- PL e - Cat four

Working temperature (° C): -10 to 55

Signal display: LED indicates working status and fault diagnosis. LED indication of input conditions

Connection: detachable terminal block, screw contacts

Test output: 4

Storage temperature (° C): -20+ eighty-five

MSC connector: Yes

Connected to MSC bus: Yes

Packaging dimensions W x H x L (mm): 36 x 127 x 113

Power supply (VDC): 24 ± 20%

Size HxWxD (mm): 108 x 22,5 x 114,5

Protection level: IP 20 for enclosure - IP 2X for wiring board

Tightening method: Guide rail fastening, in accordance with EN 50022-35 standard

Gross weight (g): 135,4

Contact information: 15359293870

WhatsApp:+86 15359293870

Contact person: KELLY

Email: geabbdcs@gmail.com   386353502@qq.com

Official website:

est output: 4

Storage temperature (° C): -20+ eighty-five

MSC connector: None

Connected to MSC bus: Yes

Start/restart output and EDM: 2

MCM Housing: Yes

USB input: Yes

Packaging dimensions W x H x L (mm): 36 x 127 x 113

Power supply (VDC): 24 ± 20%

Size HxWxD (mm): 108 x 22,5 x 114,5

Protection level: IP 20 for enclosure - IP 2X for wiring board

Tightening method: Guide rail fastening, in accordance with EN 50022-35 standard

Gross weight (g): 206,8
