IS420UCSCH1A Quad Core Controller

The Xunji DP fiber optic module has the characteristics of long transmission distance, rich interfaces, flexible networking, stable performance, and resistance to electromagnetic interference, making it suitable for fields such as power systems, transportation, energy monitoring, and industrial control. Supports the Profibus-DP protocol and provides dial switches to freely select 10 commonly used rates or rate adaptations for Profibus-DP. Provide a flexible combination of 1-2 independent bus electrical interfaces and 1-2 fiber optic interfaces, which can be flexibly configured according to the actual needs of the project. Supports redundant dual network and fiber optic ring network topologies, and supports point-to-point, star, chain bus, ring, and hybrid network networking methods. Support wide range dual redundant power input (12-36V DC), with bus interface 1000V isolation protection function, and support relay alarm output. Based on industrial installation requirements, a 35mm guide rail installation method is adopted.

Performance characteristics

*Supports logical independent dual Profibus DP bus and supports all predetermined communication rates in standard specifications

*Support setting the dial switch to a specific communication rate or rate adaptation

*Flexible selection of 1-2 Profibus DP electrical interfaces and 1-2 155Mbps fiber optic interfaces, supporting redundant dual network and fiber ring network topologies

*Fiber optic communication distance of over 20km, 155Mbps, high-speed optical interface better supporting long-distance reliable transmission of burst data

*5 dual color LED status indicators, fiber optic link and power failure relay output alarms

Contact information: 15359293870

WhatsApp:+86 15359293870

Contact person: KELLY

Email: geabbdcs@gmail.com   386353502@qq.com

Official website:

Terminal style: pluggable

Allowable cross-sectional area of flexible AWG conductor: 24-12 AWG

Height dimension: 101.4 mm

Width dimension: 22.5 mm

Depth dimension: 120 mm

Net weight: 105 g

Total weight: 115 g
