Dimension: |
35’’x35’’x44’’ |
Model item |
Tubular, U-panel, 4-panel, Baffle |
Material: |
Virgin PP material |
Color: |
White, Beige, Black, Green, Blue etc. |
Feature: |
Recyclable |
Lamination: |
1 or 2 side lamination or BOPP lamination |
Top Option: |
Duffle skirt, filling spout |
Inner liner： |
Tubular or Form fit liner or EOVA liner |
Bottom Option: |
Flat, Discharge spout |
Usage: |
Fertilizer, Industrial use or Construction |
Fabric weight: |
60g/㎡- 250g/㎡ |
Sewing: |
Normal or lock stitch or Chain stitch |
Loop Option: |
Cross corner, side seam or fully bottom |
Packing： |
On bales or Pallets as customer's require |
Safety Loading: |
500kgs - 3000kgs |
Safety factor: |
3:1, 5:1, 6:1 |
Product feature and Application
1 ton big bag also belongs to big bag, Normally it should be considered the following features before using the bag:
● Lifting Options: Cross corner, Side seam, Fully bottom lifting loops
● Filling Options: Duffle skirt, Filling spout, Top fully open
● Discharge Options: Flat bottom, Discharge spout
● Construction Type: U Panel, 4 Panel, Circular (Tubular shape) panel, Baffle etc.
● Liners: Form Fitted Liner, Tube Liner, Baffle Liner or Other liners.
● Sewing Options (Sift Resistance Construction):
Standard, Single Dust proof Stitch, Double Dust proof Stitch, Triple Dust proof Stitch (With Felt), Over-lock Stitch with Safety Stitch and other according to clients' require.
1 ton big bag are widely used in Chemicals, construction materials, plastic raw materials, Mineral products, Firewood,and other types of powder, granules, block goods packaging; And our company can also provide Food grade, Ventilated firewood, Baffle bag, conductive and UN bags.
Production Process
Normally the 1 ton big bag produced under the following Eight steps:
① 100% New polypropylene material tested good for production.
② Melting the pp material and draw bench out fiber thread for weaving fabric.
③ Weaving fabric and lifting straps .
④ Cutting the fabric into suitable size and shape according to specific requirement.
⑤ The workers sewing the big bags in clean sewing house.
⑥ The bags should be dust-proof treatment.
⑦ QA and QC inspection
⑧ Packaging on pallets or bales according to customer's requirement and ready for delivery.
Product Specification
Dimension: |
35''x35''x40'' |
Model item: |
PP bulk big bag for single trip |
Material: |
Virgin PP material |
Design: |
U-panel with 4 side seams |
Feature: |
Recyclable |
Lamination: |
30 micron lamination with 1% UV |
Filling Spout: |
14''x18'' |
Inner liner： |
Tubular shape |
Discharge spout: |
14''x18'' |
Usage: |
Chemical material or Mineral |
Fabric: |
12X12X1600D |
Sewing: |
Dead-lock stitching type, length of stitch |
Lifting loops: |
Side seam, 7cm width sewn into side vertical |
||
Safety Loading: |
2200lbs at 5:1 |
Printing: |
2-side, single Color (Dark Blue) |
Sewing Thread |
1000Dx 2plys high tenacity polyester |
Packing： |
On bales or Pallets as customer's require |
What are Bulk Big Bags?
Bulk Big Bags or Flexible Intermediate Bulk Containers, are made of polypropylene woven fabric with lifting loops that allow the bulk container to be filled from top and discharged from the bottom.
Bulk Big Bags are suitable for the transportation of the following:
● Chemicals
● Pharmaceuticals
● Fertilizers
● Food Products
● Grains and Seeds
● Construction Materials such as sand or gravel
● Plastics
ISO-21898 Standard for Non-Hazardous Duty bulk bags.
● Hazardous Duty bulk bags: UN Model Regulations & DOT 49 CFR
● Food Grade Bulk Big Bags: FDA, BRC, HAACP, GMP, Certified Clean Room.
● IEC 61340 Standard for Electrostatic Hazardous Duty FIBC bulk containers.
Our bags can be manufactured to fulfill your specific requirements. The height, diameter, and length of the bulk bag and spouts, fabric with coated or uncoated, and whether a polyethylene liner is needed will be specified according to the type of products which will be shipped.
We also produce inner liners for ensuring protection of your products and liners available in variety of types and styles according to your require.
Which style bag is the most suitable for your application?
● Circular, seamless, or Tubular bulk big bags
Bulk big bag with seamless made from pp woven fabric on a circular loom and cut to a suitable bag height. This eliminates the need for vertical seems. The tubular shape design is ideal option for fine or powder materials. Bottom of bag can be square or circle shape available.
● U-Panel Bags
U-Panel big bags consists of a large “U” piece of fabric with 2 side panels sewing to each side to fulfill a bag shape. This style bag will maintain a square shape when filled, especially for bags with baffles. U-panel big bags can offer high safe working loading weight and solid durability.
4 Panel Bags
4 Panel big bag constructed from 4 separate fabric panels which are sewn together at the edges to form a bag. A separate square sheet of fabric is used to make the bottom of the bulk bag.
Baffled Bags
Baffled bulk bags are typically 4-panel or U-panel or Circular bags which using internal fabric baffles to improve the bag's squareness and stability. These bags are designed to maximize storage and save shipping space.
FIBC Bulk Bag Options
● UN Certified
UN Certified bulk bags are specifically designed to store and transport hazardous materials.
When hazardous goods are packed in bags, the UN mark for the product should be printed on the body of bulk big bag.
● Food Grade
Food grade bulk bags that are made for food contact and food related products. It should be manufactured in BRC and AIB certified facilities. These bags are made from virgin polypropylene resin meeting with FDA food grade standard. Our food grade bags can also provided with LDPE or LLDPE inner liners approved by pharmaceutical and food usage.
● Electrostatic Properties.
1. Type A: With no special electrostatic safety features.
2. Type B: Type B bags are not able to generate brush discharges.The wall of big bag can provide a breakdown voltage of 6 kilo-volts or even less.
3. Type C: Also named conductive big bag which constructed from electrically conductive fabric weaved within conductive thread or tapes to prevent electrostatic charges on grounding.
4. Type D: Also known as anti-static big bag, normally regarding to those bags which have anti-static properties without grounding requirements.
Bulk Big Bag manufacturing Facility
Our world Class Manufacturing Facility produces bulk big bags, PP woven fabric, Inner liner, Webbing or lifting straps.
Bag Facility Capacity:
● 8,000 FIBC Bags and 50,000 PP Woven Bags per Day.
● 100,000 meters of woven fabric per Day.
● 25,000 meters of PE liners per Day.
● 40,000 meters of Lamination per Day.
● 120,000 meters of Webbing per Day.
