Part Number: 812826
Power
DC
Sensing Beam
Visible Red Laser
PFM Output
Yes
IP Rating
IP67
Sensing Mode (General)
Proximity
Sensing Mode (Detailed)
Background/Foreground Suppression
Housing Style
Rectangular
Device Type
Sensor
Primary Housing Material
ABS
Laser Classification
Class 2
Input Output
Discrete
Connection
Integral QD
Quick Disconnect Type
M12
Max Sensing Distance (mm)
10000
Minimum Sensing Distance (mm)
50
Power Supply
10-30 V dc
Adjustments
Push Button; Remote Teach
Number of Pins
4
Discrete (Switched) Outputs
2 NPN/PNP Configurable
Max Operating Temperature (°C)
50
Min Operating Temperature (°C)
-10
Minimum Response Time (ms)
2
Laser Control
Yes
Max Ambient Light (Lux)
up to 5000 lux at 1000 mm and up to 2000 lux at 2000 mm
Feature: Remote Teach
Yes
Feature: Clear Object Detection
Yes
Feature: Timing (Hold/Delay)
Yes
Feature: Pump-in/ Pump-out
Yes
Feature: Quick Disconnect
Yes
IO Link
Yes
