EN STANDARD STEEL RAIL
What is EN Standard Steel Rail?
EN Standard Steel Rail is a common type of steel rails,which are produced according to EN 13674-1-2003 standard. Usually, EN Standard Steel Rail is mainly made by Material R260/R350HT. The Sizes of EN Standard Steel Rail include: 49 E1, 50 E2, 50 E4, 54 E1, etc. The main length of EN Standard Steel Rail is 12-25m.
Types of EN Standard Steel Rail
The common EN Standard Steel Rails includes about 12 sizes,such as 49 E1,49 E2,50 E1,50 E2,50 E4,50 E5,50 E6,54 E1,54 E2,54 E3,55 E1,60 E1 Railroad steel rail.
Specifications of EN Standard Steel Rail
EN standard steel rail | |||||||
Size | Dimension(mm) | Weight | Material | Length | |||
Head(mm) | Height(mm) | Bottom(mm) | Web(mm) | ||||
49 E1 | 67 | 149 | 125 | 14 | 49.39 | R260/R350HT | 12-25m |
49 E2 | 67 | 148 | 125 | 14 | 49.1 | R260/R350HT | 12-25m |
50 E1 | 65 | 153 | 134 | 15.5 | 50.37 | R260/R350HT | 12-25m |
50 E2 | 72 | 151 | 140 | 15 | 49.97 | R260/R350HT | 12-25m |
50 E4 | 70 | 152 | 125 | 15 | 50.46 | R260/R350HT | 12-25m |
50 E5 | 67 | 148 | 135 | 14 | 49.9 | R260/R350HT | 12-25m |
50 E6 | 65 | 153 | 140 | 15.5 | 50.9 | R260/R350HT | 12-25m |
54 E1 | 70 | 159 | 140 | 16 | 54.77 | R260/R350HT | 12-25m |
54 E2 | 67.01 | 161 | 125 | 16 | 53.82 | R260/R350HT | 12-25m |
54 E3 | 67 | 154 | 125 | 16 | 54.57 | R260/R350HT | 12-25m |
55 E1 | 62 | 155 | 134 | 19 | 56.03 | R260/R350HT | 12-25m |
60 E1 | 72 | 172 | 150 | 16.5 | 60.21 | R260/R350HT | 12-25m |
Supplier of EN Standard Steel Rail
Signum Rail is a reliable steel rail material supplier in China. If you want to inquire more details about the EN Standard Steel Rail, please feel free to contact Signum Rail. We’ll feed back to you as soon as possible.
Service of EN Standard Steel Rail supplied by Signum
European Standards and CE Marking
5 years warranty.
Customization service according to your need.
More details about American standard steel rail, please feel free to contact Signum Rail.
Railroad Steel Rail and Railroad Rail Accessories Supplier, Signum Rail.
