Crossed roller bearings XSI140744-N 814x648x56mm for Container Spreade
Bearing structure:Crossed roller slewing bearing
Bearing factory items:VSI140744-N
Bearing old type:VSI140744N
Original:Made in China
The delivery time:20-30 days
Bearing boundary Dimension:814 MM
ID(inner diameter)/B:648 MM
Width/Height/thickness:56 MM
Basic dynamic load rating, Radial Cr:195 KN
Basic static load rating, Radial Cor:745 KN
The seaport name:Shanghai or Tianjin or qingdao seaport
The bearing working speed:1000 rpm
Outer Ring material:42CrMo, 50Mn
Inner Ring material:42CrMo, 50Mn
Rolling roller/ball brand LYC ball
Teeth data
Do 660mm
M 6
Teeth number 110
Bearing boundary inch size:32.04’’x25.51’’x2.20’’
Bearing outer diameter inch:32.04’’
Bearing inner diameter inch size:25.51’’
Bearing height inch:2.20’’
Weight:58 KGS
Clearance:C1 C2 C3
Quality standard:GB307 Rolling bearing technical requirement
Outer Ring and Inner Ring heat treatment:HRC55-62
Lubrication:Oil or Grease oil hole and oil groove in the outer ring
The bearing cage material:Brass cage
HS code:8482100090
Payment term:T/T or L/C at sight
The delivery time:620-30 days
Service:offer drawing and technical support
We JHB slewing bearing had offered to Spain Germany France Poland Brazil India and son
