Lubricating Oil Ageing Characteristics Tester DIN51352

This instrument is suitable for measuring the aging characteristics of petroleum-based lubricating oil, and the evaporation loss during the measurement process does not exceed 15% (m/m), with or without additives, petroleum-based lubricating oil. Also suitable for lubricating oils with antioxidant additives and with ash cleaning dispersants.

1. Applicable standard: GB/T12709 DIN51352

2. Temperature control method: high-quality PID digital temperature controller

3. Temperature control accuracy: normal temperature~200±0.2℃

4. Heating method: oil bath heating (or choose metal bath heating)

5. Power of the whole machine: 2KW

6. Working unit: 4 tubes

8. Working power supply: AC220V/50Hz

9. Timing method: digital display timer

10. Instrument size: 530*480*500mm

11. Net weight: 35KG

1. The instrument is a desktop, including a stainless steel bath and a flowmeter.

2. Stainless steel structure with ceramic coating;

3. Stainless steel drain valve, efficient thermal insulation effect;

4. Electronic stirrer with stainless steel paddle and paddle;

5. Stainless steel heater;

6. Precision flowmeter with needle valve and calibration certificate. Flow up to 2 l/min;

7. Air filter with glass wool;

8. High-quality Omron PID thermostat, digital display temperature, accuracy 0.1℃

9. Operating temperature range: room temperature~200°C;

10. Safety measures to prevent overheating or low liquid level.
