Help CenterWindturbine Blade Lifter Trailer
Related Products
• Carrist Blade Lifter could make the wind blade lift,during wind blade transportation, leveling and rotate itself to avoid various obstacles such as trees, mountains and wires, and effectively solve the problem of wind power blade transportation in mountainous areas.
• The blade is directly fix to the blade lifter and lifted in midair to transport the super long blade with a short total length of trailer.
• During transportation, the hydraulic control can make the wind blade rotate 360 °, the wind blade can rotate 360 ° through the lower slewing bearing and annular slide, and the maximum opening angle of the wind blade is 60 ° through the expansion and contraction of the oil cylinder, which can reduce the counter weight added.
• During transportation, if the wind is strong, the wind blade can rotate 360 degrees to avoid the wind, and participate in the balance through counterweight to ensure transportation safety.
•
BLADE LIFTER CTWB series SPECIFICATIONS
Dimention: |
10420*3400*3865mm |
Lifting angle: |
0-36 degree |
Lifting mode: |
duel cylinder lifting |
Rotate mode: |
4 motor drive |
Rotate of blade: |
2 motor drive |
Control: |
manual+wireless control |
Counter weight size: |
1600*1400mm |
Shifting distance: |
0-4000mm |
Shifting mode: |
duel cylinder push |
Weighing mode: |
4 point weight |
Capacity: |
510 ton*m |
Dead weight: |
47,000kgs |
