Negotiable
MOQ: 4000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
SSHX
Place of Origin:
China
Model Number:
S3030***
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
SSHX
Place of Origin
China
Model Number
S3030***
Certification
ROHS
Storage Temperature(℃)
,
Operating Temperature(℃)
,
Viewing Angle(°)
120
Emitting Color
Other, Bi-Color
Product Parameters
1-1 Electrical / Optical Characteristics at Ts=25°C
| Item | Symbol | Test Condition | Value | Unit | ||
| Min. | Typ. | Max. | ||||
| Forward Voltage | VF | IF=350mA | 2.8 | — | 3.4 | V |
| Reverse Current | IR | VR=5V | — | — | 10 | μA |
| Luminous Flux(White) | Φ | IF=350mA | 115 | 135 | 160 | lm |
| Luminous Flux (Amber) | Φ | IF=350mA | 82 | 100 | 116 | lm |
| Viewing Angle | 2θ1/2 | IF=350mA | — | 120 | — | deg |
1-2 Absolute Maximum Ratings at Ts=25°C
| Parameter | Symbol | Rating | Unit |
| Power Dissipation | Pd | 2710 | mW |
| Forward Current | IF | 350 | mA |
| Peak Forward Current | IFP | 700 | mA |
| Reverse Voltage | VR | 5 | V |
| Electrostatic Discharge | ESD | 2000 | V |
| Operating Temperature | Topr | -40～+100 | ℃ |
| Storage Temperature | Tstg | -40～+100 | ℃ |
| Junction Temperature | Tj | 125 | ℃ |
Notes：
1. 1/10 Duty cycle, 10ms pulse width.
2. The above forward voltage measurement allowance tolerance is ±0.1V.
3. The above color coordinates measurement allowance tolerance is ±0.005.
4. The above luminous intensity measurement allowance tolerance ±10%.
