Just as you would create custom designs for cost and time saving purposes, we also possess the ability to save you further time and expense by offering numerous post-extrusion magnesium product fabrication processes in-house .
Meifu Technology specializes in the following, but are not limited to, custom magnesium fabrication capabilities.
ONE-STOP SOLUTION
• A number of excellent production equipment.
• Mature process control.
• Advanced testing equipment.
• Excellent traceability system.
• Professional quality management personnel.
• Produced under the condition of non-oxygen casting and electromagnetic stirring.
• The whole industry chain production mode.
• Quick R&D iterations of new recipes.
• Quick life cycle of production.
• Save your costs.
• Quick delivery from sufficient inventory.
Typical Extruded Magnesium Shapes
• Magnesium extrusions can be designed and manufactured in a wide range of shapes. At Meifu magensium, we have an inventory of standard dies for the following extrusions:
• Angles with sharp or rounded corners.
• Bars in rectangular or square-hexagonal shapes.
• Channels with sharp or rounded corners.
specification for magnesium plate
• width: 10mm-400mm(Extrued)-Thickness:5mm-80mm
• width: 50mm-1200mm(Rolling)-Thickness:0.5mm-2mm
Grade:
| GB/T5153-2003 Grades and chemical composition of wrought magnesium and magnesium alloys | |||||||||||||
| Grade | Chemical composition (mass fraction)/% | ||||||||||||
| Al | Zn | Mn | Ce | Zr | Ca | Be | Si | Fe | Cu | Ni | Single impurity | total impurities | |
| AZ31B | 2.5-3.5 | 0.60-1.4 | 0.20-1.0 | ≤0.04 | ≤0.08 | ≤0.003 | ≤0.01 | ≤0.001 | ≤0.05 | ≤0.30 | |||
| AZ31S | 2.4-3.6 | 0.50-1.5 | 0.15-0.4 | ≤0.10 | ≤0.005 | ≤0.05 | ≤0.005 | ≤0.05 | ≤0.30 | ||||
| AZ31T | 2.4-3.6 | 0.50-1.5 | 0.05-0.4 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | ≤0.05 | ≤0.30 | ||||
| AZ40M | 3.0-4.0 | 0.20-0.8 | 0.15-0.5 | ≤0.01 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | ≤0.01 | ≤0.30 | |||
| AZ41M | 3.7-4.7 | 0.80-1.4 | 0.30-0.6 | ≤0.01 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | ≤0.01 | ≤0.30 | |||
| AZ61A | 5.8-7.2 | 0.40-1.5 | 0.15-0.5 | ≤0.10 | ≤0.005 | ≤0.05 | ≤0.005 | ≤0.30 | |||||
| AZ61M | 5.5-7.0 | 0.50-1.5 | 0.15-0.5 | ≤0.01 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | ≤0.01 | ≤0.30 | |||
| AZ61S | 5.5-6.5 | 0.50-1.5 | 0.15-0.4 | ≤0.10 | ≤0.005 | ≤0.05 | ≤0.005 | ≤0.05 | ≤0.30 | ||||
| AZ62M | 5.0-7.0 | 2.0-3.0 | 0.20-0.5 | ≤0.01 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | ≤0.01 | ≤0.30 | |||
| AZ63B | 5.3-6.7 | 2.5-3.5 | 0.15-0.6 | ≤0.08 | ≤0.003 | ≤0.01 | ≤0.001 | ≤0.30 | |||||
| AZ80A | 7.8-9.2 | 0.20-0.8 | 0.12-0.5 | ≤0.10 | ≤0.005 | ≤0.05 | ≤0.005 | ≤0.30 | |||||
| AZ80M | 7.8-9.2 | 0.20-0.8 | 0.15-0.5 | ≤0.01 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | ≤0.01 | ≤0.30 | |||
| AZ80S | 7.8-9.2 | 0.20-0.8 | 0.12-0.4 | ≤0.10 | ≤0.005 | ≤0.05 | ≤0.005 | ≤0.05 | ≤0.30 | ||||
| AZ91D | 8.5-9.5 | 0.45-0.9 | 0.17-0.4 | 0.0005-0.003 | ≤0.08 | ≤0.004 | ≤0.025 | ≤0.001 | ≤0.01 | ||||
| M1C | ≤0.01 | 0.50-1.3 | ≤0.05 | ≤0.01 | ≤0.01 | ≤0.001 | ≤0.05 | ≤0.30 | |||||
| M2M | ≤0.20 | ≤0.30 | 1.3-2.5 | ≤0.01 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.007 | ≤0.01 | ≤0.20 | |||
| M2S | 1.2-2.0 | ≤0.10 | ≤0.05 | ≤0.01 | ≤0.05 | ≤0.30 | |||||||
| ZK61M | ≤0.05 | 5.0-6.0 | ≤0.10 | 0.30-0.90 | ≤0.01 | ≤0.05 | ≤0.05 | ≤0.05 | ≤0.005 | ≤0.01 | ≤0.30 | ||
| ZK61S | 4.8-6.2 | 0.45-0.80 | ≤0.05 | ≤0.30 | |||||||||
| ME20M | ≤0.20 | ≤0.30 | 1.3-2.2 | 0.15-0.35 | ≤0.01 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.007 | ≤0.01 | |||
