Parameter:
|
phone lens surface IR drying tunnel furnace(TM-IR-S) Parameter: Model NoTM-IR-SConveyorbelt width(mm)650mmLamp power800W X10Conveyor speed380/7.5(Each section)Heating temperatureRoom temperature ~ 200 ºC (Adjustable)Total power380V,9KWDimensions2850*1150*1700Weight300KG Applications: It is apply to the surface IR drying of mobile phone lenses, glass and other materials.
Features: 1.Insulation structure: the structure of the reflow oven mode, the box Carton insulation shield isolation structure, substantially reducing the surface temperature of the furnace, to reduce the impact on the environment. 2.Temperature control: Taiwan original ML solid state relay controller with automatic power adjustment, power fluctuations small features. 3.Heat pipe installation: arranged on top of the furnace, even reasonable, lugs with high temperature wire. 4.Air transport way: hot air circulation around the loop transport wind way, uniform heating. 5.Imported Talfon or stainless steel net, the speed of transmission is steady, move smoothly and without noise. 6.Imported electrothermal control elements, accuracy high to control the temperature. 7.Imported digital-display adjusted temperature control elements control the temperature sensitivity.
hot tags: Electric Infrared Oven, Electric Dryer, Electric IR Tunnel Dryer, Electric IR tunnel machine, Electric Drying equipment, Electric Tunnel oven machine, Electric Drying tunnel equipment, Electric Tunnel dryer, Electric Dry machine, Electric Infrared Heater , Electric Drying oven, Electric IR Drying Machine Payment Terms:TT/LC/ Western Union |
|
Applications:
It is apply to the surface IR drying of mobile phone lenses, glass and other materials.
Features:
1.Insulation structure: the structure of the reflow oven mode, the box Carton insulation shield isolation structure, substantially reducing the surface temperature of the furnace, to reduce the impact on the environment.
2.Temperature control: Taiwan original ML solid state relay controller with automatic power adjustment, power fluctuations small features.
3.Heat pipe installation: arranged on top of the furnace, even reasonable, lugs with high temperature wire.
4.Air transport way: hot air circulation around the loop transport wind way, uniform heating.
5.Imported Talfon or stainless steel net, the speed of transmission is steady, move smoothly and without noise.
6.Imported electrothermal control elements, accuracy high to control the temperature.
7.Imported digital-display adjusted temperature control elements control the temperature sensitivity.
If you have any question, please contact us!
Name: SHENZHEN TAMPRINTER PRINTING MACHINERY LIMITED
Address: 111, Fourth Industrial Zone, Guanlan Town, Shenzhen518110
Contact : Mr. Tam Liu (Manager)
Send Inquiry to This Supplier
