Product Introduction
It is an instrument used to measure the thickness of materials and objects. In industrial production, it is often used to continuously or sample measure the thickness of products (such as steel plates, steel strips, thin films, paper, metal foil, and other materials).
product details
Brand: Yingpeng
Model: YP-120A Bluetooth version
Measurement principle: Magnetic principle
Measurement principle: used to detect the thickness of non-magnetic coatings on the surface of magnetic metals such as steel (such as paint, powder spraying, galvanizing, chromium coating, electrophoresis, etc.)
Matrix: Iron based
Measurement range: 0-1500 μ M
Measurement accuracy: ± (3% H+1.5um)
Thinnest substrate: 0.4mm
Bluetooth transmission: supported
Resolution: Resolution: 0.1 μ M/1 port
Minimum curvature radius: minimum curvature convex 5am: concave 25mn
Minimum measurement area: 18 * 15m
Power supply: Three No. 7 batteries
External dimensions: 126mn * 64mm * 28=day
Weight: 106g
Film thickness: 4 pieces
model
YP-120
(Single use)
YP-120A Bluetooth Edition
YP-130 (dual use)
YP-130A
YP-3000 (dual use)
Bluetooth version
measuring principle
Magnetic principle
Magnetic principle
Magnetic and Eddy Current Principles
Magnetic and Eddy Current Principles
Magnetic and Eddy Current Principles
Magnetic principle
purpose
Used for detecting magnetism
The thickness of non-magnetic coatings on surfaces of metals such as steel (such as paint, powder spraying, galvanizing, chromium coating, electrophoresis, etc.)
Used for detecting magnetism
The thickness of non-magnetic coatings on surfaces of metals such as steel (such as paint, powder spraying, galvanizing, chromium coating, electrophoresis, etc.)
Used to detect the thickness of non-conductive coatings on metal (magnetic and non magnetic) surfaces, such as measuring the thickness of paint on pot irons, and measuring the thickness of paint powder on aluminum surfaces
Used to detect the thickness of non-conductive coatings on metal surfaces (magnetic and non magnetic). Measure the thickness of paint on the iron, and the paint powder on the aluminum surface
Final thickness measurement, etc
Used to detect the thickness of non-conductive coatings on metal surfaces (magnetic and non magnetic). Measure the thickness of paint on the iron, and the paint powder on the aluminum surface
Final thickness measurement, etc
Used to detect the thickness of non-magnetic coatings on the surface of magnetic metals such as steel (such as paint, powder spraying, galvanizing, coating, electrophoresis, anti-corrosion coating, etc.)
matrix
Iron based
Iron based
Iron based/distillate based
Iron based
Iron based/aluminum based
Iron based
Bluetooth transmission
/
support
/
support
/
/
measuring range
0-1500 μ M
0-1500 μ M
0-1500um
0-1500 μ M
0-3000 μ M
0-5000um
measurement accuracy
± (3% H+1.5um)
± (3% H+1.5um)
Thinnest substrate
0.4mm
resolving power
Resolution: 0.1 μ M/1 port
Minimum radius of curvature
Minimum curvature convex 5am: concave 25m
