Hot Seller Roller Press Briquetting Machine For Power Presses

Name: Hot Seller Roller Press Briquetting Machine For Power Presses
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 10000 Set / Sets per Month
Payment Terms:T/T L/C

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Packaging Details

The packing is complete

Product Description

YHG Series Dry Powder High Pressure Briquetting Machine

Model	YHG-0.5	YHG-1.5	YHG-3.0	YHG-5.0	YHG-8.0	YHG-10.0
Roller Diameter(mm)	φ299	φ367	φ522	φ738	φ760	φ858
Roller Width(mm)	180	183	196	210	225	300
Capacity(t/h)	0.5	1.2-1.4	2.5-3.0	4.5-5.5	7.5-8.5	8.0-9.5
Main Reducer	ZQ650	ZQ850	ZS1250	ZS1450	ZS1650	ZS1650
Main Motor	18.5	37	55	75	90-110	110-132
Pre-pressure Motor(kw)	7.5	11	15	18.5	18.5	22
Pre-pressure Reducer	WHC-125	WHC-160	WHC-200	WHC-210	WHC-210	WHC-250
Remarks: Above capacity is based on material specific gravity 1.3, briquette size: φ353020mm
Roller material adopts 9Cr2Mo
Pre-pressure motor is speed motor

Introduction:

Coal slime briquetting press machine also known as briquetting machine, briquette making machine, coal briquette machine, ball press, or briquette press,but in China people always call it briquette machine.This coal briquette machine is mainly used for various mining material, metallurgical materials , industrial wastes etc such ascoal,coal slurry,bitumite, lignite, brown coal,coke powder, steel slag,bag filters dust, furnace flue dust ,manganese, mill scales, carbon black...

· The required size of raw material is less than 1mm should be controlled between 30-40%, and that between 1 mm to 2mm grain size should be 30-40%, The maximum size of materials are no more than 3mm should be about 20%,also can be 0-5mm.

· The moisture should be 8-12%(the moisture have a great influence on forming briquettes,also keep raw materials with binder is keep moisture evenly.

· In order to avoid damage of the roller and shaft that material should never have allowed with iron or other high hardness lumpy materials.

· Binder and other additives should be prepared by user, our company also will provide the formular of binder, however the user should know more about binder by themsleves.

Technical Parameter:

XM Series Coal Briquetting Machine

Model	Reducer	Ratio	Roller Size(mm)	Main Shaft Speed(r/min)	Matched Power(kw)	Capacity(t/h)	Pressure Type
XM290	ZQ350	1:31.5	290*200	12-14	5.5	0.9-1.0	Constant Pressure
XM360	ZQ350	1:31.5	360*250	12-14	7.5	1.5-2.0	Constant Pressure/Hydraulic Pressure
XM400	ZQ400	1:31.5	400*250	12-14	7.5	2.5-3.5
XM430	ZQ400	1:31.5	430*250	12-14	11	3.5-4.5
XM500	ZQ650	40.17	500*470	10-12	37	7.5-8.5
XM650	ZQ850	40.17	650*470	9-11	45	9-10
XM750	ZQ1000	40.17	750*570	9-11	90	13-14
XM850	ZQ1250	50	850*570	8-10	110	15-17
Remarks: Above capacity is based on material specific gravity 0.8, briquette size: φ50*33mm
Roller material is 65Mn, high chrome alloy and 9Cr2Mo
According to different material adjust machine parameter to meet customer production

KF Series Mineral Powder Briquetting Machine

Model	Reducer	Ratio	Roller Size	Main Shaft Speed(r/min)	Matched Power(kw)	Capacity(t/h)	Pressure Type
KF500-371-280	ZQ500	40.17	370*280	8-10	11	6.5-7.5	Constant Pressure/Hydraulic Pressure
KF650-500-300	ZQ650	40.17	500*300	8-10	37	8.5-9.5
KF850-650-300	ZQ850	40.17	650*300	8-10	55	10.5-11.5
KF1250-750-350	ZS1250	50	750*350	7-9	110	13.5-14.0
KF1450-850-350	ZS1450	50	850*350	7-9	132	15.0-16.0
KF560-1000-350	ZSY560	50	1000*350	7-9	150	17.0-20.0
Remarks: Above Capacity is based on material specific gravity 2, briquette size:φ50*33mm
Roller material is 65Mn, high chrome alloy and 9Cr2Mo.
According to different material adjust machine parameter to mmet customer production
