Ladder Belt Flat Flex Belt

Ladder Belt Flat Flex Belt thumbnail-1
Ladder Belt Flat Flex Belt thumbnail-2
Ladder Belt Flat Flex Belt thumbnail-3
Ladder Belt Flat Flex Belt thumbnail-4
Ladder Belt Flat Flex Belt photo-1
Ladder Belt Flat Flex Belt photo-2
Ladder Belt Flat Flex Belt photo-3
Ladder Belt Flat Flex Belt photo-4
US$ 3 - 21 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Brand Name:
RISEN
Place of Origin:
China
Model Number:
RS01
Contact Supplier Request Quote Chat Now
Hebei Risen Imp&exp Trading Co.,ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN;QINGDAO
Delivery Detail:
5 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name RISEN
Place of Origin China
Model Number RS01
Material Other, SS304
Type Flat Belt
Standard or Nonstandard Standard

Ladder Wire Mesh Conveyor Belts are also know as Flat Flex Conveyor Belt,is a simple but effective style of conveyor belt.The ladder belt with S-hooks run in straight applications but can also be executed as curved belts with a fixed inside radius.Flat uniform surface for gentle product handling.High tensile rods which resist permanent distortion and reduce down-time.Easy belt assembly and disassembly due to its simple open construction.It is widely used in many kinds of machine for food,cooling,heating,cleaning,baking,due to it with a large open surface area,and easier to make your line hygienic.

PARAMETER:


1. Flat flex wire mesh conveyor belt introduction

Flat flex conveyor belts are usually gear transmission belt, with good ventilation advantages, tension evenly, fine workmanship, the flat flex belts with a flexible rotation, good stability, High temperature, pressure resistance, corrosion resistance, long life and so on.

Flat flex conveyor belts are used with a single-layer structure, lighter, the use of sprocket drive. Large open area (opening 70-85%), often used in the lighter weight of the product cooling, frying, baking, drying, heating, decoration, wrapped powder and packaging equipment.


2. Flat flex wire mesh conveyor belt data sheet




Item Flat flex wire mesh belt
Material  304 stainless steel 316 stainless steel 201 stainless steel
Wire diameter

1.0mm-3.0mm
Rod picth

 4.3 - 20mm
Rod width

200 -3600mm

Note: Pitch is generally customized according to clients' requirements, which is a non-standard conveyor belt.




3. Flat flex wire mesh conveyor belt Application

Flat flex conveyor belts are mainly used in for quick-frozen food, fried food, sugar machine, chocolate coating with a variety of bread and pastry food baking conveyor line. Flat flex conveyor belts are used in the food industry for the production of the following products: small dessert, fish products, pizza, vegetables, bread, flour, cakes, meat, candy, potatoes, biscuits, chocolate, nuts and fruit.
