Adrf6650acpz-rl7 Converter ADI Original Stock

Adrf6650acpz-rl7 Converter ADI Original Stock thumbnail-1
Adrf6650acpz-rl7 Converter ADI Original Stock thumbnail-2
Adrf6650acpz-rl7 Converter ADI Original Stock thumbnail-3
Adrf6650acpz-rl7 Converter ADI Original Stock photo-1
Adrf6650acpz-rl7 Converter ADI Original Stock photo-2
Adrf6650acpz-rl7 Converter ADI Original Stock photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
ADI
Place of Origin:
Alderney
Model Number:
Adrf6650acpz-rl7
Contact Supplier Request Quote Chat Now
Shenzhen Nanbeihang Electronic Development Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ADI
Place of Origin Alderney
Model Number Adrf6650acpz-rl7
Package 750
D/C 22+

describe

Adrf6650 is a highly integrated down converter, which integrates dual mixer, dual digital switching attenuator, dual digital variable gain amplifier, phase locked loop (PLL) and voltage controlled oscillator (VCOs). In addition, the adrf6650 integrates two fast enable inputs for radio frequency (RF) balancing, serial gain control (SGC) and time division duplex (TDD) operation.

The on-chip RF balance enables the adrf6650 to support 50 Ω terminated RF input. The integrated passive mixer provides a highly linear down conversion for a 200 MHz, sliding, intermediate frequency (if) window. Adrf6650 uses a wideband square wave limited local oscillator (LO) amplifier to achieve RF bandwidth from 450 MHz to 2700 MHz. Unlike the traditional narrow-band sine wave Lo amplifier solution, this amplifier allows lo to be applied above or below the RF input in a very wide bandwidth.

Adrf6650 provides two alternatives for generating differential Lo input signals: internally through an on-chip fractional-N synthesizer with low phase noise VCOs, or externally through a low phase noise LO signal. The integrated pll/vco enables continuous Lo coverage from 450 MHz to 2900 MHz. The PLL reference input supports a wide frequency range and includes an integrated reference divider before the phase frequency detector (PFD).

Adrf6650 is manufactured using the advanced silicon germanium (SiGe) bipolar complementary metal oxide semiconductor (BiCMOS) process. It is available in a 56 lead, ROHS compatible, 8 mm × 8 mm, lead frame chip scale pack (lfcsp) pack with an exposed pad. Performance is specified at a maximum paddle temperature of − 40 ° C to+105 ° C.

FEATURES
Dual down-converter with integrated fractional-N PLL/VCO
RF: 450 MHz to 2700 MHz continuous
LO frequency: 450 MHz to 2900 MHz,
high-side or low-side injection
43 dB gain control range
Gain control with up/down and SPI
Integrated RF balun for single-ended 50 Ω inputs
Power supply: 3.3 and 5 V
8 mm × 8 mm, 56-lead LFCSP package
APPLICATIONS
Multiband/multistandard cellular base station diversity
receivers
Wideband radio link diversity downconverters

Multimode cellular extenders and picocells




Product Tags: Adrf6650acpz-rl7 , converter , ADI
