Gas Cylinders , Refillable Welded Steel Cylinders, Steel Gas Cylinders
US$ 15 - 52
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
WellCare
Place of Origin:
China
Model Number:
HKSC-00
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
25 days
Related Products
-
Gas Cylinder Supplier, Gas Tanks, Gas BottleUS$ 15 - 52MOQ: 50 Pieces -
High Pressure Gas Cylinders, Gas Cylinder System, Gas Cylinder StorageUS$ 15 - 52MOQ: 50 Pieces
-
China Aluminum Gas Cylinders, Valves, Gas CylinderUS$ 20 - 35MOQ: 50 Pieces
-
High Pressure Aluminum Gas Cylinders, Aluminium Cylinders | WellCare Gas CylindersUS$ 20 - 35MOQ: 50 Pieces
-
Aluminum Gas Cylinder, Disposable Gas Cylinder, Beverage CylinderUS$ 20 - 35MOQ: 50 Pieces
Brand Name
WellCare
Place of Origin
China
Model Number
HKSC-00
Material
Steel
Use
Oxygen
Pressure
High
Main specs on 40L Gas Cylinders:
-1). Water capacity: 40 Liter; Mat.: 37Mn;
OD= 219 mm; W. P/T. P.: 15/25Mpa; Wall thickness: 5.7 mm; G. W.: ~47kg;
Height: 1, 345 mm (W/O cylinder cap); Gas(O2): 6M3.
-2). Color: As GREEN preferred;
-3). Connecting thread:
-4). Applied standard: ISO 9809-3;
-5). Packing: Each with nylon bag or as preferred(based on bilateral agreement).
What we can promise for you:
*High quality and security gas cylinders;
*Competitive unit price in the market;
*Fast delivery (3~4 weeks);
*Best after-sale service.
Our manufactured Seamless Steel Gas Cylinders are made from moblie high-pressure vessels. They are manufactured with the most advanced technology, machinery and equipment in the word. They are ideal for holding permanent gases, such as oxygen, hydrogen, argon and carbon dioxide,and etc.
| Outside diameter (mm) | Capacity(L) | Height (mm) | Weight (kg) | Material | Wall Thickness (mm) | test pressure (MPa) | Working Pressure (MPa) |
| 108 | 2.0 | 320 | 3.75 | 37Mn | 5.7 | 22.5 | 15 |
| 108 | 2.0 | 317 | 3.72 | 37Mn | 5.7 | 22.5 | 15 |
| 121 | 4.0 | 485 | 6.16 | 37Mn | 5.7 | 22.5 | 15 |
| 121 | 4.0 | 470 | 5.95 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 4.0 | 492 | 5.7 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 5.0 | 578 | 7.52 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 7.0 | 713 | 9.84 | 37Mn | 5.7 | 22.5 | 15 |
| 152 | 7.0 | 648 | 9.57 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 10.0 | 935 | 13.90 | 37Mn | 5.7 | 22.5 | 15 |
| 152 | 10.0 | 846 | 12.6 | 37Mn | 5.7 | 22.5 | 15 |
| 159 | 10.0 | 805 | 14.15 | 37Mn | 5.7 | 22.5 | 15 |
| 159 | 12.0 | 950 | 16.34 | 37Mn | 5.7 | 22.5 | 15 |
| 159 | 15.0 | 955 | 19 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 25.0 | 885 | 33 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 32.0 | 1090 | 40 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 40.0 | 1310 | 48.0 | 37Mn | 5.7 | 22.5 | 15 |
| 232 | 40.0 | 1170 | 45.3 | 37Mn | 5.7 | 22.5 | 15 |
| 232 | 46.7 | 1345 | 51 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 47.0 | 1355 | 52 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 50.0 | 1600 | 57.0 | 37Mn | 5.7 | 22.5 | 15 |
| 232 | 50.0 | 1440 | 56.0 | 34CrMo4 | 5.7 | 30 | 20 |
| Outside diameter (mm) | Capacity(L) | Height (mm) | Weight (kg) | Material | Wall Thickness (mm) | Test Pressure (MPa) | Working Pressure (MPa) |
| 108 | 2.0 | 320 | 3.75 | 37Mn | 5.7 | 22.5 | 15 |
| 108 | 2.0 | 317 | 3.72 | 37Mn | 5.7 | 22.5 | 15 |
| 121 | 4.0 | 485 | 6.16 | 37Mn | 5.7 | 22.5 | 15 |
| 121 | 4.0 | 470 | 5.95 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 4.0 | 492 | 5.7 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 5.0 | 578 | 7.52 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 7.0 | 713 | 9.84 | 37Mn | 5.7 | 22.5 | 15 |
| 152 | 7.0 | 648 | 9.57 | 37Mn | 5.7 | 22.5 | 15 |
| 140 | 10.0 | 935 | 13.90 | 37Mn | 5.7 | 22.5 | 15 |
| 152 | 10.0 | 846 | 12.6 | 37Mn | 5.7 | 22.5 | 15 |
| 159 | 10.0 | 805 | 14.15 | 37Mn | 5.7 | 22.5 | 15 |
| 159 | 12.0 | 950 | 16.34 | 37Mn | 5.7 | 22.5 | 15 |
| 159 | 15.0 | 955 | 19 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 25.0 | 885 | 33 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 32.0 | 1090 | 40 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 40.0 | 1310 | 48.0 | 37Mn | 5.7 | 22.5 | 15 |
| 232 | 40.0 | 1170 | 45.3 | 37Mn | 5.7 | 22.5 | 15 |
| 232 | 46.7 | 1345 | 51 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 47.0 | 1355 | 52 | 37Mn | 5.7 | 22.5 | 15 |
| 219 | 50.0 | 1600 | 57.0 | 37Mn | 5.7 | 22.5 | 15 |
| 232 | 50.0 | 1440 | 56.0 | 34CrMo4 | 5.7 | 30 | 20 |
