Product Use:
Upper low temperature test chamber apply to the defense industry, aerospace, electronics, and related materials at high altitudes ( low pressure ) under various temperature adaptability test and verify its performance index.
Functional:
characteristics In the box and the reinforcement of high strength thick steel plate.If you need more models about our test equipment, please reference our chamber-testing（.）com
Two - stage imported compressor and refrigeration parts ensure the long-term stability device
Function:
1. To simulate test environment with various altitude environments .
2. It is especially important for defense and aerospace applications where pressure and vacuum conditions are even more intense
3. Application fields: Include Aviation, aerospace, communications, electronics, electrical appliances etc.
4. Test Purpose: to guarantee the maximum quality and reliability while products or material might encounter at various altitude levels.
Safety devices:
1. Power owed to reverse protection
2. No fuse switch
3. Dry compustion prevention switch
4. The water protection switch
5. Over-temperature protection
6. Motor overload protection
7. The high-pressure compressor protection
8. The overheating protection of compressor
9. The over-current protection of compressor
10. The over-current protection of vacuum pump
| Internal volume (L) | 80L |
150L |
225L |
400L |
1000L |
|
Inner box size
W*H*D(cm)
|
40*50*40 | 50*60*50 |
60*70*60 |
70*80*70 |
100*100*100 |
|
Carton size
W*H*D(cm)
|
115*180*110 |
125*190*130 |
135*200*150 |
150*215*165 |
180*235*200 |
Temperature range |
Low temperature R:-20℃;L:-40℃;S:-60℃ → high temperature +150℃ |
||||
Temperature uniformity |
±2℃ |
||||
Control stability |
±2.0℃ |
||||
Temperature deviation |
≤2.0℃ |
||||
Rising and cooling rate |
Heating up 1.0～4.0℃/min; cooling down 0.7～2.0℃/min |
||||
Cooling method |
Two-stage refrigeration |
||||
Cooling method |
water-cooled |
||||
Inner box material |
SUS304 stainless steel(3.0 thickening) |
||||
| Outer box material | Electrostatic spraying of steel plate |
||||
| Refrigeration Compressors | French Taikang Hermetic Compressor/German Bitzer Semi-hermetic Compressor |
||||
| Controller | LCD touch screen | ||||
| Protector | Leakage circuit breaker, phase loss, reverse phase protection, overheating, overload protection | ||||
| Electric source | AC 380V | ||||
Advantage:
Ø 24 hours online
Ø 35 years experiences
Ø Sample chamber of each model
Ø Best price, fast delivery
Ø OEM,ODM
Ø Oversea offices
Ø Own import and export business license
Ø ISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
