Help CenterTumbler Belt Shot Blasting Abrator Machine Wheel Crawler Shot Blaster
Related Products
-
Tumble Belt Shot Blasting Machine for Nuts and Bolts Surface TreatmentUS$ 2000 - 6000MOQ: 1 Piece -
Q326 Q324 Q3210 Tumble Belt Shot Blasting Machine Crawler Belt Shot Blasting MachineUS$ 2000 - 6000MOQ: 1 Piece
-
Smaller Casting Parts Surface Treatment Crawler Shot Blasting MachineUS$ 2000 - 6000MOQ: 1 Piece
-
Tumble Rubber Belt Shot Blasting Machine for Foundry Plant Crawler Shot BlasterUS$ 2000 - 6000MOQ: 1 Piece
-
Spinner Hnager Hook Shot Blasting MachineUS$ 1000 - 29999MOQ: 1 Set
Operation
The loading device loads work pieces directly into the blast machine from containers, pallets or so-called charging baskets. The work pieces slide through the open loading door and onto the advancing caterpillar tread.
The loader subsequently returns to its initial position. The blasting process begins after the loading door is automatically closed and then locked. After the blasting period ends, the door opens automatically. The freshly blasted work pieces are removed in sequence by a take-off conveyor, or by emptying them directly into containers provided by the customer.
The blasting abrasive is continuously cleaned, recirculated and reused. An abrasive metering device feeds the cleaned abrasive from the abrasive storage bunker to the high-performance turbines.
A fan unit creates the partial vacuum necessary to maintain dust-free operation of the blasting unit. Extracted air is cleaned in a special filter unit.
Technical Parameter
item | units | Q326C | QR3210 | 15GN | 28GN |
productivity | t/h | 0.6-1.2 | 1.5-2.5 | 5-6 | 10-12 |
feeding amount | kg | 200 | 600 | 1300 | 3500 |
max.weight of single piece | kg | 10 | 30 | 230 | 363 |
diameter of end disk | mm | 650 | 1000 | 1092 | 1245 |
efectve volume | m3 | 0.15 | 0.3 | 0.43 | 0.79 |
shot-blasting capacity | kg/min | 100 | 250 | 480 | 700 |
air volume for dedusting | m3/h | 2200 | 5000 | 5300 | 6500 |
power consumption | kw | 12.6 | 24.3 | 49.3 | 64.5 |
outline dimension | mm | 3681*1650*5800 | 3972*2600*4768 | 4597*3262*5709 | 5300*5432*6814 |
