NS8002 SOP-8 Nsiway 2.4W Mono Class AB Audio Power Amplifier

2.4W Mono Class AB Audio Power Amplifier

1 Characteristics

Output power: 2 4W (RL=4 Ω, THD=10%)

Low leakage current in power-off mode: 1uA (typical)

High level shutdown

Adopting SOP8 packaging

Adjustable external gain

Voltage range 3.0V-5.25V

No need to drive output coupling capacitors, bootstrap capacitors, and buffer networks

Unit gain stability

2 Application scope

Laptop computer

Desktop computer

Low voltage audio system

3 Description

NS8002 is an AB class bridge output audio power amplifier.

Its application circuit is simple, requiring only a few peripheral devices. Output not required

To connect external coupling capacitors or lift capacitors and buffer networks. SOP-8 seal

Installed, more suitable for portable systems.

NS8002 can enter low-power shutdown mode through control, from

And reduce power consumption. The Gain–bandwidth product is up to 2.5 MHz and the unit gain is stable

Fixed. By configuring peripheral resistors, the voltage gain of the amplifier can be adjusted,

Easy to apply.

NS8002 offers SOP-8 packaging with a rated operating temperature range

-40 ℃ to 85 ℃.
