Vacuum Insulated VIP Panel for Construction Insulation

Vacuum Insulated VIP Panel for Construction Insulation

Vacuum Insulation panels (VIP) in English Vacuum Insulation Panel for short, is one of the Vacuum thermal Insulation material, by filling the composite core material and Vacuum protection surface layer, and it effectively avoid caused air convection heat transfer, thus can greatly reduce the thermal conductivity, is less than 0.004 w/m.k, and does not contain any ODS material, has the characteristics of environmental protection and high efficiency and energy saving, is currently the world's most advanced and efficient heat preservation material.

Application:
VIP is mainly used for thermal insulation, such as household refrigerator, yacht refrigerator, mini refrigerator, car refrigerator, cryogenic freezer, electric water heater, vending machines, freezers, cold storage container, refrigerated vehicles, cold stores, aerospace, shipping and medical incubators,building wall thermal insulation, LNG storage ,pipe insulation and transportation, especially suitable for fields such as building energy-saving renovation projects.

Specification industrial VIP:

Note:Customized products can be provided according to customer requirements

Performance and advantages:

1. Compared with other materials, vacuum insulation panels have extremely low thermal conductivity, thin thickness, small volume, and light weight.

2.Excellent insulation effect, equivalent to 5 times that of conventional polystyrene board, 4 times that of extruded board, and 2.8 times that of polyurethane. Vacuum insulation board used in construction

The thermal coefficient is below 0.008W/(m·K). The thermal conductivity of industrial vacuum insulation panels can reach 0.002-0.004w/m.k, which is superior to traditional insulation materials 1/10 of the thermal coefficient.

3.High insulation: E-glass fiber has high temperature resistance, good mechanical properties, and high chemical stability, making it the best insulation material

4.The unit weight is light, and it is not easy to fall off after construction, with high safety.

5.Integrating insulation and decoration engineering organically makes the construction process simpler than traditional insulation systems.

6.Convenient construction, it can be directly pasted like ceramic tiles, greatly shortening the construction period and saving costs.

7.The insulation material is inorganic insulation material, which is A-grade fireproof and non combustible.

8.Non toxic, green and environmentally friendly, with long service life
