Low Noise Angled Conveyor Belt Low Energy Consumption

FOB Price

US$ 3500 - 4500 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T L/C PayPal Western Union Other
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Carbon Steel	Certification	ISO9001:2000, CE
Warranty	1 Year	Color	Grey
Voltage	380V	After-sales Service	Overseas Engineer Service Available
Customized	Non-Customized	Condition	New
Material Feature	Other, wear resistant	Energy Saving	Energy Saving
Transport Package	20GP Container	Specification	B650
Trademark	Shisheng Machinery	Origin	Henan

Product Description

Low Noise Angled Conveyor Belt Low Energy Consumption

Low Noise Angled Conveyor Belt Low Energy Consumption Scope of Application:

Large angle belt conveyor can be used for bulk materials such as coal, coke, sand, aggregate, sand, broken glass, asphalt raw materials, stone, fertilizer, lime, etc., and it can be transported in the working environment humidity range of -15 °C to +40 °C. Various bulk materials with a specific gravity of 0.7-3.0t/m3.The corrugated belt conveyor can transport a variety of bulk materials in horizontal, inclined, vertical and variable angle directions, from coal, ore, sand to fertilizer and grain. The material size is not limited and can range from very small particle sizes to large particle sizes of 400 mm. The delivery rate can range from 1 m3/h- 6,000m3/h.

Main Features of Large Angle Belt Conveyor:

1. Save floor space and save investment. Simple structure, reliable operation and low noise. Low energy consumption;

2. Large conveying capacity, strong versatility, convenient maintenance, parts such as rollers and ordinary belt conveyors;

3. Conveyor inclination: 0°-90°;

4. Easy to interface with other equipment. Easy to arrange;

5. Wide range of applications: metallurgy, mining, docks, environmental protection, food, chemicals, building materials, etc.

Technical Parameter of Large Angle Belt Conveyor:

Carrying idlers form	Belt speed(m/s)	Belt Width B(mm)
		500	650	800	1000	1200	1400
		Throughput Q(t/s)
Trough roller	0.8	78	131	-	-	-	-
	1.0	97	164	278	435	655	891
	1.25	122	206	348	544	819	1115
	1.6	156	264	445	696	1048	1427
	2.0	191	323	546	853	1284	1748
	2.5	232	391	661	1033	1556	2118
	3.15	-	-	824	1233	1858	2528
	4.0	-	-	-	-	2202	2996
Parallel rollers	0.8	41	67	118	-	-	-
	1.0	52	88	147	230	345	460
	1.25	66	110	184	288	432	588
	1.6	84	142	236	368	553	753
	2.0	103	174	289	451	677	922
